![[IMAGE] of](P_2x5_014_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 580 V |
![[IMAGE] of](P_2x5_014_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date 2/5/2007
| Part | ID |
|---|---|
| BBM | BBM_014-2x5 |
| VHDI | 2x5_335 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XE4K3KT | 05B |
| ROC1 | XE4K3KT | 14A |
| ROC2 | XE4K3KT | 13B |
| ROC3 | XE4K3KT | 13A |
| ROC4 | XE4K3KT | 11B |
| ROC5 | XE4K3KT | 18A |
| ROC6 | XE4K3KT | 18B |
| ROC7 | XE4K3KT | 15D |
| ROC8 | XE4K3KT | 17D |
| ROC9 | XE4K3KT | 12A |
Inspected by Lockwood Gale on date 2/9/2007
| LR_dev | 0.079 |
| LL_dev | 0.073 |
| FINAL COMMENT by Lockwood Gale | No assembly problem. All wirebonds OK. ROC5 chn 34, 35 bonds missed on 1st attempt - repaired. |
PLAQUETTE made READY for testing on 2/9/2007 by Lockwood Gale
P_2x5_014_Con 2/12/2007 9:36 AM
P_2x5_014_Con 2/12/2007 9:36 AM
P_2x5_014_C-1on 2/12/2007 10:19 AM
P_2x5_014_C-1on 2/12/2007 10:19 AM
PLAQUETTE TESTED on 2007-02-12 by Gino Bolla
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | ROC8 | ROC9 | |
| Ibias_DAC | 132 | 134 | 146 | 130 | 136 | 150 | 126 | 138 | 126 | 128 | |
| Vana | 125 | 135 | 139 | 117 | 141 | 158 | 122 | 141 | 137 | 131 | |
| Cal_Del | 96 | 73 | 87 | 80 | 104 | 73 | 90 | 72 | 96 | 93 | |
| Vthrs_Comp | 63 | 84 | 74 | 75 | 75 | 88 | 78 | 80 | 73 | 66 | |
| Unbumped | 0 | 0 | 64 | 28 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 66 | 28 | 0 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x5_014_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x5_014_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x5_014_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x5_014_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x5_014_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x5_014_Cno-bump-light.jpg) |
LIGHT_XML-File |
Noise MAP
![[IMAGE] of](P_2x5_014_C-1-100-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_014_C-1-100-efficiency.jpg)
| ROC0 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC0-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC0-HISTO.jpg) | MEAN = 4.308027SIGMA = 0.348743 |
| ROC1 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC1-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC1-HISTO.jpg) | MEAN = 4.468048SIGMA = 0.370713 |
| ROC2 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC2-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC2-HISTO.jpg) | MEAN = 4.607277SIGMA = 0.377017 |
| ROC3 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC3-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC3-HISTO.jpg) | MEAN = 4.484344SIGMA = 0.346514 |
| ROC4 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC4-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC4-HISTO.jpg) | MEAN = 5.308956SIGMA = 0.406877 |
| ROC5 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC5-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC5-HISTO.jpg) | MEAN = 4.925310SIGMA = 0.387356 |
| ROC6 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC6-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC6-HISTO.jpg) | MEAN = 4.735536SIGMA = 0.375003 |
| ROC7 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC7-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC7-HISTO.jpg) | MEAN = 4.959496SIGMA = 0.418565 |
| ROC8 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC8-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC8-HISTO.jpg) | MEAN = 5.318762SIGMA = 0.422759 |
| ROC9 NOISE | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC9-MAP.jpg) | ![[IMAGE] of](P_2x5_014_C-1-100-noise-ROC9-HISTO.jpg) | MEAN = 4.991266SIGMA = 0.444443 |
PLAQUETTE READY TO BE POTTED
