Sensor: S_2x5_014, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC	ROC wafer	Label
ROC0	XE4K3KT	05B
ROC1	XE4K3KT	14A
ROC2	XE4K3KT	13B
ROC3	XE4K3KT	13A
ROC4	XE4K3KT	11B
ROC5	XE4K3KT	18A
ROC6	XE4K3KT	18B
ROC7	XE4K3KT	15D
ROC8	XE4K3KT	17D
ROC9	XE4K3KT	12A

FIXED (not measured) Depletion Voltage is -50 and FIXED (not measured) suggested operational voltage is -150

Ibias_DAC, Ibias_DAC Data	132	134	146	130	136	150	126	138	126	128
Vana, VanaData	125	135	139	117	141	158	122	141	137	131
TestDdata ,TestD Plots	0	2	65	17	0	0	5	6	0	0
LightData ,Light Plots	0	0	65	28	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	BAD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	BAD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD

Noise MAP

Efficiency MAP

ROC0 NOISE			MEAN = 4.371585 SIGMA = 0.334395
ROC1 NOISE			MEAN = 4.522624 SIGMA = 0.356437
ROC2 NOISE			MEAN = 4.611682 SIGMA = 0.363138
ROC3 NOISE			MEAN = 4.489350 SIGMA = 0.339093
ROC4 NOISE			MEAN = 5.291405 SIGMA = 0.427002
ROC5 NOISE			MEAN = 4.911247 SIGMA = 0.379563
ROC6 NOISE			MEAN = 4.702942 SIGMA = 0.362623
ROC7 NOISE			MEAN = 4.933903 SIGMA = 0.408116
ROC8 NOISE			MEAN = 5.300064 SIGMA = 0.448853
ROC9 NOISE			MEAN = 4.998771 SIGMA = 0.455939

Comment (if any):

P_2x5_014_C-1.html,

P_2x5_014_C-2.html,

P_2x5_014_C.html,

End testing time: 11:38 AM
