P_2x4T_166_C-11

Production testing

Date:8/6/2007

Operator: Gino Bolla

start testing time:10:27 AM

Sensor: S_2x4T_16, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROCROC waferLabel
ROC0XH4KFBT74B
ROC1XH4KFBT74A
ROC2KMNG2DT44D
ROC3XH4KFBT73A
ROC4XH4KFBT74D
ROC5XH4KFBT74C
ROC6XH4KFBT73D
ROC7XH4KFBT73C

This plaquette was reworked. Old results here

Inspected by Arndt Kirk on date 7/31/2007
LR_dev0.005
LL_dev0.015

PLAQUETTE GLUED with HALF PRESSURE

FINAL COMMENT by Arndt KirkAssembled at HALF-PRESSURE. no assembly problems. reworked BBM No wirebonding problems (reworked BBM - 2nd bond foot on original ROCs).

PLAQUETTE made READY for ENCAPSULATION on 7/31/2007 by Arndt Kirk

PLAQUETTE encapsulated on 7/31/2007 by Ozhan Koybasi

PLAQUETTE made READY for testing on 7/31/2007 by Ozhan Koybasi

P_2x4T_166_Con 7/31/2007 1:18 PM

P_2x4T_166_C-1on 7/31/2007 1:25 PM

P_2x4T_166_C-2on 8/1/2007 1:42 PM

P_2x4T_166_C-3on 8/1/2007 1:50 PM

P_2x4T_166_C-4on 8/2/2007 12:24 PM

P_2x4T_166_C-5on 8/2/2007 12:32 PM

P_2x4T_166_C-6on 8/2/2007 12:39 PM

P_2x4T_166_C-7on 8/2/2007 12:50 PM

P_2x4T_166_C-8on 8/3/2007 12:17 PM

P_2x4T_166_C-9on 8/6/2007 9:18 AM

P_2x4T_166_C-10on 8/6/2007 9:43 AM

P_2x4T_166_C-11on 8/6/2007 10:27 AM

Depletion Voltage is -48 and suggested operational voltage is -88
Ibias_DAC, Ibias_DAC Data 160 162 156 148 164 158 158 150
Vana, VanaData 144 124 127 131 130 145 133 125
CalDelData and plots8381756893818082
VthrCompData and plots8482808382767575
TestDdata ,TestD Plots11022918110
LightData ,Light Plots12020001
Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD GOOD GOOD
Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP at VMAX

[IMAGE] of

Efficiency MAP

[IMAGE] of

EXTRA DACs for NOISE

VHldDe110140120140130100105130
Vsf140135140140140145140140
VoffsetOp9075608580755565
VIbias_PH1001051051009510510095
ROC0 NOISE[IMAGE] of [IMAGE] of MEAN = 3.793870

SIGMA = 0.307934
ROC1 NOISE[IMAGE] of [IMAGE] of MEAN = 4.553906

SIGMA = 0.374493
ROC2 NOISE[IMAGE] of [IMAGE] of MEAN = 4.884040

SIGMA = 0.395930
ROC3 NOISE[IMAGE] of [IMAGE] of MEAN = 4.823404

SIGMA = 0.382245
ROC4 NOISE[IMAGE] of [IMAGE] of MEAN = 3.902771

SIGMA = 0.324112
ROC5 NOISE[IMAGE] of [IMAGE] of MEAN = 4.357168

SIGMA = 0.393744
ROC6 NOISE[IMAGE] of [IMAGE] of MEAN = 4.580321

SIGMA = 0.358523
ROC7 NOISE[IMAGE] of [IMAGE] of MEAN = 4.445733

SIGMA = 0.363230

Comment (if any): FInally

This Device have been tested 11Times prior to this one and here are the links to the previous tests:

P_2x4T_166_C-1.html,

P_2x4T_166_C-10.html,

P_2x4T_166_C-2.html,

P_2x4T_166_C-3.html,

P_2x4T_166_C-4.html,

P_2x4T_166_C-5.html,

P_2x4T_166_C-6.html,

P_2x4T_166_C-7.html,

P_2x4T_166_C-8.html,

,

,

End testing time: 11:06 AM
