![[IMAGE] of](P_2x3B_067_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3B_067_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date 2/8/2007
| Part | ID |
|---|---|
| BBM | BBM_067-2x3B |
| VHDI | 2x3_448 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W29_X64K5ST | 05C |
| ROC1 | W29_X64K5ST | 05B |
| ROC2 | W29_X64K5ST | 04D |
| ROC3 | W33_XC4K5LT | 67C |
| ROC4 | W33_XC4K5LT | 67D |
| ROC5 | W33_XC4K5LT | 68A |
Inspected by Lockwood Gale on date 2/16/2007
| LR_dev | 0.020 |
| LL_dev | 0.049 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. Roc 3 channel 1, 2 attempts, no other wirebonding problems. |
PLAQUETTE made READY for testing on 2/16/2007 by Lockwood Gale
P_2x3B_067_Aon 2/16/2007 1:51 PM
P_2x3B_067_Aon 2/16/2007 1:51 PM
P_2x3B_067_A-1on 2/16/2007 2:12 PM
P_2x3B_067_A-1on 2/16/2007 2:12 PM
PLAQUETTE TESTED on 2007-02-16 by Isaac Childres
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 118 | 138 | 132 | 140 | 132 | 142 | |
| Vana | 135 | 134 | 123 | 148 | 137 | 135 | |
| Cal_Del | 86 | 78 | 86 | 78 | 84 | 73 | |
| Vthrs_Comp | 67 | 82 | 74 | 89 | 83 | 84 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_067_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_067_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_067_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_067_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_067_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_067_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 95 | 120 | 125 | 90 | 115 | 105 |
| Vsf | 140 | 140 | 140 | 150 | 140 | 140 |
| VoffsetOp | 80 | 100 | 75 | 95 | 105 | 95 |
| VIbias_PH | 95 | 105 | 95 | 100 | 105 | 100 |
Noise MAP
![[IMAGE] of](P_2x3B_067_A-1-100-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_067_A-1-100-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 95 | 120 | 125 | 90 | 115 | 105 |
| Vsf | 140 | 140 | 140 | 150 | 140 | 140 |
| VoffsetOp | 80 | 100 | 75 | 95 | 105 | 95 |
| VIbias_PH | 95 | 105 | 95 | 100 | 105 | 100 |
PLAQUETTE READY TO BE POTTED
