P_2x3B_067

P_2x3B_067_A-1

Production testing

Date:2/16/2007

Operator: Isaac Childres

start testing time:2:12 PM

Sensor: S_2x3B_06, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 W29_X64K5ST 05C

ROC1 W29_X64K5ST 05B

ROC2 W29_X64K5ST 04D

ROC3 W33_XC4K5LT 67C

ROC4 W33_XC4K5LT 67D

ROC5 W33_XC4K5LT 68A

ROC	ROC wafer	Label
ROC0	W29_X64K5ST	05C
ROC1	W29_X64K5ST	05B
ROC2	W29_X64K5ST	04D
ROC3	W33_XC4K5LT	67C
ROC4	W33_XC4K5LT	67D
ROC5	W33_XC4K5LT	68A

Depletion Voltage is -52 and suggested operational voltage is -92

Ibias_DAC, Ibias_DAC Data 118 138 132 140 132 142

Vana, VanaData 135 134 123 148 137 135

CalDelData and plots 86 78 86 78 84 73

VthrCompData and plots 67 82 74 89 83 84

TestDdata ,TestD Plots 0 0 0 0 0 0

LightData ,Light Plots 0 0 0 0 0 0

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	95	120	125	90	115	105
Vsf	140	140	140	150	140	140
VoffsetOp	80	100	75	95	105	95
VIbias_PH	95	105	95	100	105	100

ROC0 NOISE			MEAN = 5.008678 SIGMA = 0.402855
ROC1 NOISE			MEAN = 4.776822 SIGMA = 0.360695
ROC2 NOISE			MEAN = 4.910560 SIGMA = 0.383013
ROC3 NOISE			MEAN = 5.132484 SIGMA = 0.393827
ROC4 NOISE			MEAN = 4.990685 SIGMA = 0.387420
ROC5 NOISE			MEAN = 4.506853 SIGMA = 0.348029

Comment (if any): Good.

This Device have been tested 1Times prior to this one and here are the links to the previous tests:

P_2x3B_067_A.html,

End testing time: 2:33 PM

Ibias_DAC, Ibias_DAC Data	118	138	132	140	132	142
Vana, VanaData	135	134	123	148	137	135
CalDelData and plots	86	78	86	78	84	73
VthrCompData and plots	67	82	74	89	83	84
TestDdata ,TestD Plots	0	0	0	0	0	0
LightData ,Light Plots	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
