| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x5_099_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 46 V |
| Operational Voltage 86 V |
Parts committed by Bolla Gino on date 1/31/2007
| Part | ID |
|---|---|
| BBM | BBM_099-2x5 |
| VHDI | 2x5_301 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W28_X54K5TT | 34D |
| ROC1 | W28_X54K5TT | 34C |
| ROC2 | W28_X54K5TT | 34A |
| ROC3 | W28_X54K5TT | 33D |
| ROC4 | W28_X54K5TT | 33B |
| ROC5 | W28_X54K5TT | 14D |
| ROC6 | W28_X54K5TT | 15A |
| ROC7 | W28_X54K5TT | 15B |
| ROC8 | W28_X54K5TT | 15C |
| ROC9 | W28_X54K5TT | 15D |
Inspected by Lockwood Gale on date 2/5/2007
| LR_dev | 0.073 |
| LL_dev | 0.080 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for testing on 2/5/2007 by Lockwood Gale
P_2x5_099_Aon 2/5/2007 4:08 PM
P_2x5_099_Aon 2/5/2007 4:08 PM
PLAQUETTE TESTED on 2007-02-05 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | ROC8 | ROC9 | |
| Ibias_DAC | 144 | 122 | 152 | 134 | 132 | 134 | 140 | 132 | 128 | 134 | |
| Vana | 144 | 142 | 143 | 131 | 124 | 128 | 132 | 127 | 137 | 134 | |
| Cal_Del | 77 | 84 | 71 | 89 | 82 | 80 | 78 | 79 | 66 | 88 | |
| Vthrs_Comp | 76 | 75 | 79 | 73 | 80 | 76 | 77 | 74 | 91 | 72 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x5_099_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x5_099_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x5_099_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x5_099_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x5_099_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x5_099_Ano-bump-light.jpg) |
LIGHT_XML-File |
Noise MAP
![[IMAGE] of](P_2x5_099_A-1-100-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_099_A-1-100-efficiency.jpg)
| ROC0 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC0-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC0-HISTO.jpg) | MEAN = 4.556868SIGMA = 0.336168 |
| ROC1 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC1-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC1-HISTO.jpg) | MEAN = 5.489509SIGMA = 0.424369 |
| ROC2 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC2-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC2-HISTO.jpg) | MEAN = 5.765718SIGMA = 0.429770 |
| ROC3 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC3-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC3-HISTO.jpg) | MEAN = 4.876062SIGMA = 0.401801 |
| ROC4 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC4-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC4-HISTO.jpg) | MEAN = 4.763709SIGMA = 0.359087 |
| ROC5 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC5-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC5-HISTO.jpg) | MEAN = 4.993696SIGMA = 0.384482 |
| ROC6 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC6-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC6-HISTO.jpg) | MEAN = 5.494572SIGMA = 0.455125 |
| ROC7 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC7-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC7-HISTO.jpg) | MEAN = 5.188125SIGMA = 0.421259 |
| ROC8 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC8-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC8-HISTO.jpg) | MEAN = 6.245116SIGMA = 0.500538 |
| ROC9 NOISE | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC9-MAP.jpg) | ![[IMAGE] of](P_2x5_099_A-1-100-noise-ROC9-HISTO.jpg) | MEAN = 4.297547SIGMA = 0.328462 |
PLAQUETTE READY TO BE POTTED
