P_2x4B_088

P_2x4B_088_A

Parts committed by Bolla Gino on date 11/14/2006

Part	ID
BBM	BBM_088-2x4B
VHDI	2x4_309

ROC ROC wafer Label

ROC0 W21_XA4KFIT 66A

ROC1 W21_XA4KFIT 65D

ROC2 W21_XA4KFIT 65C

ROC3 W21_XA4KFIT 65B

ROC4 W21_XA4KFIT 43A

ROC5 W21_XA4KFIT 43B

ROC6 W21_XA4KFIT 43C

ROC7 W21_XA4KFIT 43D

ROC	ROC wafer	Label
ROC0	W21_XA4KFIT	66A
ROC1	W21_XA4KFIT	65D
ROC2	W21_XA4KFIT	65C
ROC3	W21_XA4KFIT	65B
ROC4	W21_XA4KFIT	43A
ROC5	W21_XA4KFIT	43B
ROC6	W21_XA4KFIT	43C
ROC7	W21_XA4KFIT	43D

Inspected by Lockwood Gale on date 11/21/2006

LR_dev 0.026

LL_dev 0.051

FINAL COMMENT by Lockwood Gale No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/21/2006 by Lockwood Gale

P_2x4B_088_Aon 11/21/2006 3:57 PM P_2x4B_088_A-1on 11/21/2006 4:20 PM

PLAQUETTE TESTED on 2006-11-21 by Isaac Childres

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 56 V

Operational Voltage 96 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	133	139	142	139	140	127	135	138
Vana	127	113	142	120	120	128	130	126
Cal_Del	86	75	83	85	81	90	85	69
Vthrs_Comp	82	73	84	86	67	61	82	89
Unbumped	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-27

Plaquette assigned to panel P4L_015
