![[IMAGE] of](P_2x4B_032_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 510 V |
![[IMAGE] of](P_2x4B_032_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 56 V |
| Operational Voltage 96 V |
Parts committed by Bolla Gino on date 4/10/2007
| Part | ID |
|---|---|
| BBM | BBM_032-2x4B |
| VHDI | 2x4_502 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XW4KFXT | 18C |
| ROC1 | XW4KFXT | 13C |
| ROC2 | XW4KFXT | 17B |
| ROC3 | XW4KFXT | 17C |
| ROC4 | XW4KFXT | 27C |
| ROC5 | XW4KFXT | 14B |
| ROC6 | XW4KFXT | 17D |
| ROC7 | XW4KFXT | 28A |
Inspected by Lockwood Gale on date 4/13/2007
| LR_dev | 0.046 |
| LL_dev | 0.049 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | No assembly problems. Assembled at HALF-PRESSURE.No wirebond problems. |
PLAQUETTE made READY for ENCAPSULATION on 4/13/2007 by Lockwood Gale
PLAQUETTE encapsulated on 4/13/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 4/13/2007 by Ozhan Koybasi
P_2x4B_032_Con 4/17/2007 9:20 AM
P_2x4B_032_Con 4/17/2007 9:20 AM
P_2x4B_032_C-1on 4/17/2007 9:41 AM
P_2x4B_032_C-1on 4/17/2007 9:41 AM
PLAQUETTE TESTED on 2007-04-17 by Gino Bolla
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 144 | 132 | 128 | 130 | 134 | 146 | 138 | 140 | |
| Vana | 158 | 133 | 124 | 122 | 129 | 141 | 111 | 115 | |
| Cal_Del | 83 | 83 | 94 | 95 | 78 | 92 | 101 | 96 | |
| Vthrs_Comp | 89 | 82 | 65 | 66 | 66 | 75 | 68 | 75 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 2 | |
| Dead | 0 | 0 | 0 | 1 | 1 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 1 | 1 | 0 | 0 | 2 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_032_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_032_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_032_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_032_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_032_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_032_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 95 | 130 | 130 | 115 | 115 | 105 | 170 | 145 |
| Vsf | 145 | 145 | 130 | 135 | 140 | 140 | 130 | 135 |
| VoffsetOp | 125 | 90 | 70 | 80 | 80 | 80 | 65 | 65 |
| VIbias_PH | 100 | 105 | 95 | 100 | 100 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x4B_032_C-1-490-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_032_C-1-490-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
