Sensor: S_2x3B_03, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | XE4KFET | 67B |
ROC1 | XE4KFET | 68C |
ROC2 | XE4KFET | 62D |
ROC3 | XE4KFET | 64C |
ROC4 | XE4KFET | 65C |
ROC5 | XE4KFET | 75A |
Ibias_DAC, Ibias_DAC Data | 142 | 144 | 132 | 144 | 144 | 126 |
Vana, VanaData | 127 | 144 | 132 | 142 | 118 | 129 | FIXED (not measured) Depletion Voltage is -50 and FIXED (not measured) suggested operational voltage is -150
TestDdata ,TestD Plots | 0 | 0 | 60 | 2 | 2 | 0 |
LightData ,Light Plots | 0 | 1 | 148 | 5 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | BAD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | BAD | GOOD | GOOD | GOOD |
Noise MAP
Noise MAP
ROC0 NOISE | ||
ROC1 NOISE | ||
ROC2 NOISE | ||
ROC3 NOISE | ||
ROC4 NOISE | ||
ROC5 NOISE | ||
ROC6 NOISE | ||
ROC7 NOISE | ||
ROC8 NOISE | ||
ROC9 NOISE |
Comment (if any):
This Device have been tested 4Times prior to this one and here are the links to the previous tests:End testing time: 3:18 PM
