P_1x2R_036_C

Parts committed by Bolla Gino on date 1/3/2007

PartID
BBMBBM_036-1x2T
VHDI1x2R_250

ROCROC waferLabel
ROC0XE4KFET74A
ROC1XE4KFET67C

Inspected by Arndt Kirk on date 1/5/2007
LR_dev0.087
LL_dev0.047
FINAL COMMENT by Arndt KirkNo assembly problems. No wirebond problem.

PLAQUETTE made READY for testing on 1/5/2007 by Arndt Kirk

P_1x2R_036_Con 1/5/2007 3:55 PM P_1x2R_036_C-1on 1/5/2007 4:10 PM

PLAQUETTE TESTED on 2007-01-05 by Gino Bolla

[IMAGE] of
IV_XML-File
Maximum Voltage 550 V
[IMAGE] of
LASER_XML-File
Depletion Voltage 58 V
Operational Voltage 98 V

ROCROC0ROC1
Ibias_DAC144138
Vana138132
Cal_Del71102
Vthrs_Comp8777
Unbumped20338
Dead00
Noisy00
Undecoded00
Total BAD20338

ASSEMBLY_XML-File SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
[IMAGE] of I_BIAS_DAC_XML-File
[IMAGE] of VANA_XML-File
[IMAGE] of DEAD_XML-File
[IMAGE] of NOISY_XML-File
[IMAGE] of UNDECODED_XML-File
[IMAGE] of LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2007-05-21
