Test Date: 2015-12-15 13:26
Analysis date: 2016-05-25 15:11
Analysis date: 2016-05-25 15:11
M-H-1-06 XRayHRQualification
Summary
| Module | Module | M-H-1-06 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 171 | |
| BumpBondingDefects | Bump Bonding Defects | 171 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.90 | 99.69 | 0.08 | 61.4 | 0 | 18.6 | 0/0 | 0 |
|
Chip 1
|
A
|
21 | 99.97 | 99.87 | 99.53 | 0.05 | 37.2 | 21 | 11.2 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.96 | 99.88 | 99.62 | 0.15 | 53.6 | 5 | 16.1 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.97 | 99.90 | 99.67 | 0.12 | 84.1 | 1 | 25.4 | 0/0 | 0 |
|
Chip 4
|
A
|
12 | 99.95 | 99.88 | 99.63 | 0.19 | 83.7 | 12 | 25.3 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.95 | 99.87 | 99.62 | 0.13 | 87.3 | 1 | 26.4 | 0/0 | 0 |
|
Chip 6
|
A
|
2 | 99.97 | 99.90 | 99.66 | 0.13 | 88.1 | 2 | 26.6 | 0/0 | 0 |
|
Chip 7
|
A
|
73 | 99.83 | 99.81 | 99.76 | 11.35 | 57.0 | 73 | 17.2 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.14 | 64.1 | 0 | 19.3 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.96 | 99.90 | 99.69 | 0.10 | 85.0 | 1 | 25.7 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.12 | 78.2 | 0 | 23.6 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.16 | 72.0 | 0 | 21.7 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.10 | 80.5 | 0 | 24.3 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.89 | 99.65 | 0.12 | 47.0 | 8 | 14.2 | 0/0 | 0 |
|
Chip 14
|
A
|
42 | 99.96 | 99.52 | -1.00 | 0.01 | 19.6 | 42 | 5.9 | 0/0 | 0 |
|
Chip 15
|
A
|
5 | 99.95 | 99.41 | -1.00 | 0.02 | 21.5 | 5 | 6.5 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 263 | |
| nWarnings | # Warnings | 46 | |
| channel_0_count | Channel 0 | 18 | |
| channel_1_count | Channel 1 | 14 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 23 | |
| message_eventid_count | Event ID mismatch | 5 | |
| message_readback_count | Readback start marker | 1 | |
| message_notokenpass_count | has NoTokenPass | 3 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
