Test Date: 2015-12-15 13:26
Analysis date: 2016-05-25 15:11
Chip 5
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 120/40 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 120/40 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 120/40 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 120/40 0/0
BumpBondingDefects # Bump Bonding Defects 120/40 1/1
Efficiency Efficiency 20/50/80 99.95/99.87/99.62
EfficiencyFit Efficiency Fit chi2/ndf: 0.13, # points: 47
EfficiencyGrade Efficiency Grade 20/50/80 A/(A)/A
HotPixelsGrade Hot Pixels Grade 120/40 A/A
HitMapGrade Hit Map Grade 120/40 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 120/40 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 120/40 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C5
Plot
fitfunction Fit [0]-[1]*x^3
Chi2NDF chi2/ndf 0.13
NumberFitPoints # fit points 47
p0 p0 99.95
p1 p1 6.57e-07
InterpolatedEfficiency20 Interpol. Efficiency 20 99.95
InterpolatedEfficiency20Error Interpol. Efficiency 20 error 0.008
InterpolatedEfficiency50 Interpol. Efficiency 50 99.87
InterpolatedEfficiency50Error Interpol. Efficiency 50 error 0.006
InterpolatedEfficiency80 Interpol. Efficiency 80 99.62
InterpolatedEfficiency80Error Interpol. Efficiency 80 error 0.025
Efficiency Map 40: C5
Efficiency Map 80: C5
Efficiency Map 120: C5
Efficiency Distr. 40: C5
Plot
N N 4160
mu μ 99.89
sigma σ 2.22
Efficiency Distr. 80: C5
Plot
N N 4160
mu μ 99.76
sigma σ 2.28
Efficiency Distr. 120: C5
Plot
N N 4160
mu μ 99.45
sigma σ 2.43
Background Map 40: C5
Plot
RealHitrate Real Hitrate 26.95 MHz/cm2
Background Map 80: C5
Plot
RealHitrate Real Hitrate 56.71 MHz/cm2
Background Map 120: C5
Plot
RealHitrate Real Hitrate 86.17 MHz/cm2
Masked Hot Pixels 120: C5
Masked Hot Pixels 40: C5
Hit Map 120: C5
Plot
RealHitrate Real Hitrate 87.26 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 1
BB Defects 120: C5
Hit Map 40: C5
Plot
RealHitrate Real Hitrate 26.38 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 1
BB Defects 40: C5
Col. Read. Unif. 120: C5
Plot
N N 12487332
mu μ 272051
sigma σ 68995.02
Col. Read. Unif. 40: C5
Plot
N N 3774481
mu μ 82248
sigma σ 20889.93
Read. Unif. over Time 120: C5
Plot
N N 14146657
mu μ 14304
sigma_th σ_th 119.60
Time unif. distribution 120: C5
Plot
chi2/ndf chi2/ndf 1.53
sigma σ 120.35
sigma_th σ_th 119.64
expectation Red curve (expected) Poisson
Read. Unif. over Time 40: C5
Plot
N N 4276902
mu μ 4324
sigma_th σ_th 65.76
Time unif. distribution 40: C5
Plot
chi2/ndf chi2/ndf 0.50
sigma σ 66.52
sigma_th σ_th 65.78
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C5
Col. Uniformity per Event: C5 120
Plot
mu μ 24.17
sigma fit error of μ 2.20
Col. Uniformity per Event: C5 40
Plot
mu μ 24.24
sigma fit error of μ 2.17
Alive Map: C5
DC Efficiency Distribution: C5
CalDel scan: C5
