Test Date: 2016-01-21 11:17
Analysis date: 2016-05-24 07:38
Analysis date: 2016-05-24 07:38
M-G-2-48 XRayHRQualification
Summary
| Module | Module | M-G-2-48 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/2/2 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 99.71/99.42/98.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "60" | Rate "130" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
0 | 99.18 | 98.44 | 96.02 | 11.54 | 49.9 | 107.2 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.93 | 99.83 | 99.50 | 0.22 | 31.9 | 68.6 | 0 | 0/0 | 0 |
|
Chip 2
|
C
|
1 | 99.93 | 99.80 | 99.37 | 0.23 | 55.9 | 119.9 | 1 | 0/0 | 0+3/13 |
|
Chip 3
|
C
|
0 | 99.63 | 99.22 | 97.88 | 6.32 | 86.3 | 182.2 | 0 | 0/0 | 1+1/0 |
|
Chip 4
|
A
|
0 | 99.81 | 99.47 | 98.35 | 3.82 | 89.1 | 190.5 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 98.84 | 98.69 | 98.20 | 4.31 | 94.0 | 201.0 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.84 | 99.43 | 0.12 | 94.4 | 201.9 | 0 | 0/0 | 0 |
|
Chip 7
|
B
|
3 | 99.66 | 99.24 | 97.87 | 4.73 | 64.7 | 139.1 | 3 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.65 | 99.50 | 99.01 | 3.09 | 62.4 | 134.1 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.79 | 99.57 | 98.87 | 1.68 | 80.7 | 173.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.82 | 99.75 | 99.53 | 0.49 | 81.4 | 174.6 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.57 | 99.35 | 98.62 | 1.36 | 69.6 | 149.4 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
9 | 99.94 | 99.82 | 99.43 | 0.20 | 70.8 | 151.7 | 9 | 0/0 | 0 |
|
Chip 13
|
A
|
3 | 99.76 | 99.56 | 98.87 | 2.54 | 43.4 | 93.3 | 3 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.94 | 99.21 | -1.00 | 0.03 | 18.3 | 39.5 | 0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.94 | 99.44 | -1.00 | 0.06 | 18.9 | 40.8 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
