Test Date: 2016-01-21 11:17
Analysis date: 2016-05-24 07:38
Chip 0
Grading
ROCGrade Final ROC Grade B
NumberOfHotPixels # Hot Pixels 60/130 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 60/130 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 60/130 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 60/130 0/0
BumpBondingDefects # Bump Bonding Defects 60/130 0/0
Efficiency Efficiency 20/50/80 99.18/98.44/96.02
EfficiencyFit Efficiency Fit chi2/ndf: 11.54, # points: 51
EfficiencyGrade Efficiency Grade 20/50/80 A/(A)/B
HotPixelsGrade Hot Pixels Grade 60/130 A/A
HitMapGrade Hit Map Grade 60/130 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 60/130 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 60/130 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C0
Plot
fitfunction Fit [0]-[1]*x^3
Chi2NDF chi2/ndf 11.54
NumberFitPoints # fit points 51
p0 p0 99.23
p1 p1 6.27e-06
InterpolatedEfficiency20 Interpol. Efficiency 20 99.18
InterpolatedEfficiency20Error Interpol. Efficiency 20 error 0.066
InterpolatedEfficiency50 Interpol. Efficiency 50 98.44
InterpolatedEfficiency50Error Interpol. Efficiency 50 error 0.054
InterpolatedEfficiency80 Interpol. Efficiency 80 96.02
InterpolatedEfficiency80Error Interpol. Efficiency 80 error 0.250
Efficiency Map 30: C0
Efficiency Map 60: C0
Efficiency Map 100: C0
Efficiency Map 130: C0
Efficiency Map 170: C0
Efficiency Distr. 30: C0
Plot
N N 4160
mu μ 99.22
sigma σ 1.34
Efficiency Distr. 60: C0
Plot
N N 4160
mu μ 98.08
sigma σ 2.35
Efficiency Distr. 100: C0
Plot
N N 4160
mu μ 97.10
sigma σ 3.03
Efficiency Distr. 130: C0
Plot
N N 4160
mu μ 95.83
sigma σ 3.91
Efficiency Distr. 170: C0
Plot
N N 4160
mu μ 93.97
sigma σ 5.22
Background Map 30: C0
Plot
RealHitrate Real Hitrate 22.95 MHz/cm2
Background Map 60: C0
Plot
RealHitrate Real Hitrate 55.39 MHz/cm2
Background Map 100: C0
Plot
RealHitrate Real Hitrate 78.77 MHz/cm2
Background Map 130: C0
Plot
RealHitrate Real Hitrate 103.84 MHz/cm2
Background Map 170: C0
Plot
RealHitrate Real Hitrate 135.55 MHz/cm2
Masked Hot Pixels 60: C0
Masked Hot Pixels 130: C0
Hit Map 60: C0
Plot
RealHitrate Real Hitrate 49.92 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 60: C0
Hit Map 130: C0
Plot
RealHitrate Real Hitrate 107.18 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 130: C0
Col. Read. Unif. 60: C0
Plot
N N 7052103
mu μ 155621
sigma σ 59948.64
Col. Read. Unif. 130: C0
Plot
N N 15146664
mu μ 334153
sigma σ 128277.03
Read. Unif. over Time 60: C0
Plot
N N 8092275
mu μ 8182
sigma_th σ_th 90.46
Time unif. distribution 60: C0
Plot
chi2/ndf chi2/ndf 1.63
sigma σ 94.64
sigma_th σ_th 90.49
expectation Red curve (expected) Poisson
Read. Unif. over Time 130: C0
Plot
N N 17375979
mu μ 17569
sigma_th σ_th 132.55
Time unif. distribution 130: C0
Plot
chi2/ndf chi2/ndf 2.70
sigma σ 144.83
sigma_th σ_th 132.59
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C0
Col. Uniformity per Event: C0 60
Plot
mu μ 22.47
sigma fit error of μ 2.20
Col. Uniformity per Event: C0 130
Plot
mu μ 22.06
sigma fit error of μ 2.19
Alive Map: C0
DC Efficiency Distribution: C0
CalDel scan: C0
