![[IMAGE] of](P_2x5_148_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x5_148_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Bolla Gino on date 2/15/2007
| Part | ID |
|---|---|
| BBM | BBM_148-2x5 |
| VHDI | 2x5_394 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W29_X64K5ST | 26D |
| ROC1 | W29_X64K5ST | 26C |
| ROC2 | W29_X64K5ST | 26B |
| ROC3 | W29_X64K5ST | 25D |
| ROC4 | W29_X64K5ST | 25A |
| ROC5 | W33_XC4K5LT | 73B |
| ROC6 | W33_XC4K5LT | 73C |
| ROC7 | W33_XC4K5LT | 73D |
| ROC8 | W33_XC4K5LT | 74A |
| ROC9 | W33_XC4K5LT | 74B |
Inspected by Arndt Kirk on date 2/20/2007
| LR_dev | 0.078 |
| LL_dev | 0.071 |
| FINAL COMMENT by Arndt Kirk | BBM joined to VHDI initially in air. Nominal joining force applied in vacuum. All bonds OK - ROC0 and 1 chn 35, and ROC2 chn 23 required multiple attempts to bond VHDI pads. |
PLAQUETTE made READY for testing on 2/20/2007 by Arndt Kirk
PLAQUETTE encapsulated on 2/21/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 2/21/2007 by Ozhan Koybasi
P_2x5_148_Aon 2/21/2007 12:19 PM
P_2x5_148_Aon 2/21/2007 12:19 PM
PLAQUETTE TESTED on 2007-02-21 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | ROC8 | ROC9 | |
| Ibias_DAC | 134 | 130 | 132 | 154 | 132 | 142 | 148 | 134 | 148 | 138 | |
| Vana | 140 | 132 | 139 | 144 | 124 | 151 | 144 | 138 | 133 | 135 | |
| Cal_Del | 67 | 75 | 71 | 64 | 87 | 76 | 67 | 74 | 65 | 72 | |
| Vthrs_Comp | 73 | 83 | 82 | 84 | 74 | 88 | 86 | 87 | 87 | 86 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 3 | |
| Dead | 9 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 4 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 9 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 7 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x5_148_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x5_148_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x5_148_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x5_148_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x5_148_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x5_148_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 95 | 125 | 100 | 95 | 130 | 95 | 95 | 100 | 120 | 125 |
| Vsf | 140 | 135 | 140 | 145 | 135 | 145 | 145 | 140 | 140 | 140 |
| VoffsetOp | 85 | 75 | 90 | 80 | 85 | 90 | 85 | 65 | 85 | 80 |
| VIbias_PH | 95 | 110 | 105 | 105 | 100 | 105 | 100 | 105 | 95 | 100 |
Noise MAP
![[IMAGE] of](P_2x5_148_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_148_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
