P_2x5_066

P_2x5_066_C

Parts committed by Bolla Gino on date 4/16/2007

Part	ID
BBM	BBM_066-2x5
VHDI	2x5_417

ROC ROC wafer Label

ROC0 X94KFJT 66A

ROC1 X94KFJT 56C

ROC2 X94KFJT 46A

ROC3 X94KFJT 36A

ROC4 X94KFJT 36C

ROC5 X94KFJT 26A

ROC6 X94KFJT 26C

ROC7 X94KFJT 05C

ROC8 X94KFJT 05D

ROC9 X94KFJT 64B

ROC	ROC wafer	Label
ROC0	X94KFJT	66A
ROC1	X94KFJT	56C
ROC2	X94KFJT	46A
ROC3	X94KFJT	36A
ROC4	X94KFJT	36C
ROC5	X94KFJT	26A
ROC6	X94KFJT	26C
ROC7	X94KFJT	05C
ROC8	X94KFJT	05D
ROC9	X94KFJT	64B

Inspected by Lockwood Gale on date 4/19/2007

LR_dev 0.034

LL_dev 0.035

PLAQUETTE GLUED with HALF PRESSURE

FINAL COMMENT by Lockwood Gale

Assembled at HALF-PRESSURE. No assembly problems. Delamination of VHDI near FOM wires, No wirebonding problems.

PLAQUETTE made READY for ENCAPSULATION on 4/19/2007 by Lockwood Gale

PLAQUETTE encapsulated on 4/20/2007 by Ozhan Koybasi

PLAQUETTE made READY for testing on 4/20/2007 by Ozhan Koybasi

P_2x5_066_Con 4/23/2007 9:30 AM

PLAQUETTE TESTED on 2007-04-23 by Gino Bolla

IV_XML-File

Maximum Voltage 440 V

LASER_XML-File

Depletion Voltage 50 V

Operational Voltage 90 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	128	132	146	132	144	142	142	144	138	134
Vana	127	127	141	131	146	141	150	135	141	143
Cal_Del	99	71	84	94	72	94	81	88	85	94
Vthrs_Comp	79	80	86	81	78	81	86	79	71	74
Unbumped	0	0	0	0	0	0	1	1	2	4
Dead	0	0	0	0	0	1	0	0	1	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	1	0	0	0	0	0	0	0	0	0
Total BAD	1	0	0	0	0	1	1	1	3	4

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

EXTRA DACs for NOISE

VHldDe	130	125	105	125	95	130	90	105	105	95
Vsf	140	140	140	135	145	145	145	140	140	140
VoffsetOp	75	60	90	75	95	95	85	80	90	100
VIbias_PH	100	100	100	100	100	105	100	100	105	100

Noise MAP

Efficiency MAP

PLAQUETTE READY TO BE SHIPPED

Shipped on date 2007-04-23
