| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x5_035_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Bolla Gino on date 11/8/2007
| Part | ID |
|---|---|
| BBM | BBM_035-2x5 |
| VHDI | 2x5_708 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W55_D3LQE4T | 52D |
| ROC1 | W55_D3LQE4T | 52C |
| ROC2 | W55_D3LQE4T | 52B |
| ROC3 | W55_D3LQE4T | 52A |
| ROC4 | W55_D3LQE4T | 33A |
| ROC5 | W55_D3LQE4T | 33B |
| ROC6 | W55_D3LQE4T | 33C |
| ROC7 | W55_D3LQE4T | 33D |
| ROC8 | W55_D3LQE4T | 34A |
| ROC9 | W55_D3LQE4T | 34D |
Inspected by Lockwood Gale on date 11/13/2007
| LR_dev | 0.072 |
| LL_dev | 0.056 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | Force used to join BBM to VHDI = 2 kg per ROC. No assembly problems. ROC 4 Ch 1, ROC 9 Ch 20, ROC 3 Ch 1, ROC 5 Ch 35, 2FL, 3 tries. No other problem wirebonding. |
PLAQUETTE made READY for ENCAPSULATION on 11/13/2007 by Lockwood Gale
PLAQUETTE encapsulated on 11/14/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 11/14/2007 by Ozhan Koybasi
P_2x5_035_Aon 11/15/2007 3:51 PM
P_2x5_035_Aon 11/15/2007 3:51 PM
PLAQUETTE TESTED on 2007-11-15 by Ozhan Koybasi
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | ROC8 | ROC9 | |
| Ibias_DAC | 158 | 172 | 158 | 156 | 150 | 148 | 160 | 148 | 156 | 158 | |
| Vana | 139 | 154 | 142 | 143 | 140 | 144 | 145 | 145 | 153 | 157 | |
| Cal_Del | 93 | 80 | 91 | 90 | 75 | 85 | 80 | 93 | 74 | 73 | |
| Vthrs_Comp | 86 | 89 | 89 | 90 | 92 | 84 | 92 | 83 | 91 | 93 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 4 | 0 | |
| Dead | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 2 | 1 | 0 | 0 | 0 | 0 | 0 | 4 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x5_035_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x5_035_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x5_035_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x5_035_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x5_035_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x5_035_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 115 | 85 | 100 | 105 | 90 | 90 | 105 | 90 | 95 | 95 |
| Vsf | 145 | 150 | 140 | 145 | 140 | 145 | 145 | 150 | 155 | 155 |
| VoffsetOp | 105 | 115 | 105 | 100 | 105 | 95 | 110 | 105 | 115 | 115 |
| VIbias_PH | 100 | 100 | 100 | 100 | 95 | 100 | 105 | 100 | 100 | 100 |
Noise MAP at VMAX
![[IMAGE] of](P_2x5_035_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_035_A-580-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_2x5_035_A-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_035_A-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
