P_2x5_026

P_2x5_026_C

Parts committed by Bolla Gino on date CCYY-MM-DD

Part	ID
BBM	BBM_026-2x5
VHDI	2x5_245

ROC ROC wafer Label

ROC0 XL4K3DT 34D

ROC1 XL4K3DT 32B

ROC2 XL4K3DT 32A

ROC3 XL4K3DT 31A

ROC4 XL4K3DT 39D

ROC5 XL4K3DT 30B

ROC6 XL4K3DT 30D

ROC7 XL4K3DT 35C

ROC8 XL4K3DT 35D

ROC9 XL4K3DT 38C

ROC	ROC wafer	Label
ROC0	XL4K3DT	34D
ROC1	XL4K3DT	32B
ROC2	XL4K3DT	32A
ROC3	XL4K3DT	31A
ROC4	XL4K3DT	39D
ROC5	XL4K3DT	30B
ROC6	XL4K3DT	30D
ROC7	XL4K3DT	35C
ROC8	XL4K3DT	35D
ROC9	XL4K3DT	38C

Inspected by Arndt Kirk on date 2006-07-25

LR_dev 0.043

LL_dev 0.065

FINAL COMMENT by Arndt Kirk No problem assembly. No wirebonding problem

PLAQUETTE made READY for testing on 2006-07-25 by Arndt Kirk

PLAQUETTE TESTED on 2006-7-26 by Stacy Kouba

IV_XML-File

Maximum Voltage 500 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	159	178	175	179	163	179	165	178	163	174
Vana	122	117	130	140	127	139	124	133	139	122
Cal_Del	91	96	79	95	89	92	101	90	73	107
Vthrs_Comp	72	72	86	81	81	74	76	77	81	81
Unbumped	1	1	1	1	124	0	0	0	12	0
Dead	0	0	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	1	1	1	1	124	0	0	0	12	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-08-23

Plaquette assigned to panel P3R_065
