P_2x5_017

P_2x5_017_C

Parts committed by Bolla Gino on date CCYY-MM-DD

Part	ID
BBM	BBM_017-2x5
VHDI	2x5_327

ROC ROC wafer Label

ROC0 XL4K3DT 03B

ROC1 XL4K3DT 04A

ROC2 XL4K3DT 05A

ROC3 XL4K3DT 06B

ROC4 XL4K3DT 13C

ROC5 XL4K3DT 13D

ROC6 XL4K3DT 14C

ROC7 XL4K3DT 14D

ROC8 XL4K3DT 15D

ROC9 XL4K3DT 16C

ROC	ROC wafer	Label
ROC0	XL4K3DT	03B
ROC1	XL4K3DT	04A
ROC2	XL4K3DT	05A
ROC3	XL4K3DT	06B
ROC4	XL4K3DT	13C
ROC5	XL4K3DT	13D
ROC6	XL4K3DT	14C
ROC7	XL4K3DT	14D
ROC8	XL4K3DT	15D
ROC9	XL4K3DT	16C

Inspected by Arndt Kirk on date 2006-07-20

LR_dev 0.044

LL_dev 0.056

FINAL COMMENT by Arndt Kirk No problem assembly. No wirebonding problem

PLAQUETTE made READY for testing on 2006-07-20 by Arndt Kirk

PLAQUETTE TESTED on 2006-7-21 by Stacy Kouba

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	168	170	156	170	167	171	184	157	174	161
Vana	121	139	127	133	138	139	138	122	135	125
Cal_Del	90	94	100	94	79	80	71	73	67	90
Vthrs_Comp	86	79	77	77	83	87	85	86	79	67
Unbumped	2	0	1	0	0	0	0	1	1	0
Dead	0	0	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	2	0	1	0	0	0	0	1	1	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-08-01

Plaquette assigned to panel P3R_018
