| Plaquette | Position | Purdue Map | FNAL Plaq. Map | FNAL Panel Map |
|---|---|---|---|---|
| P_2x5_017_C | 3 | | | |
| P_2x4B_021_C | 2 | | | |
| P_2x3B_021_C | 1 | | | |
| Panel assembly comments |
|---|
| 21Feb07/Sudhir: This panel was light tested and PTA verified by Lorenzo today 19apr07/ME: Max hv = 420V (not traceable to any plaquette) 24apr07/ME: Breakdown due to outer loop. Upgraded to A. |
