Sensor: S_2x4T_12, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC	ROC wafer	Label
ROC0	W47_DXLQF5T	13D
ROC1	W47_DXLQF5T	13A
ROC2	W47_DXLQF5T	12D
ROC3	W47_DXLQF5T	12C
ROC4	W55_D3LQE4T	66C
ROC5	W52_DOLQC8T	55D
ROC6	W55_D3LQE4T	04D
ROC7	W55_D3LQE4T	67B

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data	144	156	142	150	146	142	156	134
Vana, VanaData	144	158	134	137	144	141	154	128
CalDelData and plots	98	67	100	89	88	83	82	95
VthrCompData and plots	92	88	73	80	84	82	91	79
TestDdata ,TestD Plots	1	0	0	0	0	0	12	0
LightData ,Light Plots	0	0	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

ROC0 NOISE			MEAN = 4.307643 SIGMA = 0.335186
ROC1 NOISE			MEAN = 4.009254 SIGMA = 0.337819
ROC2 NOISE			MEAN = 4.362150 SIGMA = 0.342491
ROC3 NOISE			MEAN = 4.231571 SIGMA = 0.347085
ROC4 NOISE			MEAN = 4.338855 SIGMA = 0.351266
ROC5 NOISE			MEAN = 3.825876 SIGMA = 0.298375
ROC6 NOISE			MEAN = 3.932023 SIGMA = 0.319284
ROC7 NOISE			MEAN = 4.054681 SIGMA = 0.336055

Comment (if any):

P_2x4T_123_A-1.html,

P_2x4T_123_A-2.html,

P_2x4T_123_A.html,

End testing time: 4:11 PM
