P_2x4B_156

P_2x4B_156_A

Parts committed by Bolla Gino on date 1/22/2007

Part	ID
BBM	BBM_156-2x4B
VHDI	2x4_399

ROC ROC wafer Label

ROC0 W28_X54K5TT 66B

ROC1 W28_X54K5TT 66A

ROC2 W28_X54K5TT 65D

ROC3 W28_X54K5TT 64D

ROC4 W28_X54K5TT 43D

ROC5 W28_X54K5TT 44B

ROC6 W28_X54K5TT 45A

ROC7 W28_X54K5TT 45B

ROC	ROC wafer	Label
ROC0	W28_X54K5TT	66B
ROC1	W28_X54K5TT	66A
ROC2	W28_X54K5TT	65D
ROC3	W28_X54K5TT	64D
ROC4	W28_X54K5TT	43D
ROC5	W28_X54K5TT	44B
ROC6	W28_X54K5TT	45A
ROC7	W28_X54K5TT	45B

Inspected by Lockwood Gale on date 1/25/2007

LR_dev 0.053

LL_dev 0.063

FINAL COMMENT by Lockwood Gale No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 1/25/2007 by Lockwood Gale

P_2x4B_156_Aon 1/26/2007 12:41 PM

PLAQUETTE TESTED on 2007-01-26 by Isaac Childres

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 48 V

Operational Voltage 88 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	142	128	146	146	146	144	146	132
Vana	123	122	124	144	140	128	140	140
Cal_Del	93	86	75	86	96	80	84	81
Vthrs_Comp	70	72	73	84	82	75	81	83
Unbumped	1	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	2	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	1	0	0	0	2	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY TO BE POTTED

PLAQUETTE encapsulated on 2/1/2007 by Arndt Kirk

P_2x4B_156_A-1on 2/1/2007 3:03 PM

P_2x4B_156_A-1on 2/1/2007 3:03 PM AFTER POTTING

BAD CHANNELS COMPARISON Before/after ENCAPSULATION

ROC DEAD NOISY UNDECODED TESTD LIGHT

ROC0 0/0 0/0 0/0 1/1 1/1

ROC1 0/0 0/0 0/0 0/0 0/0

ROC2 0/0 0/0 0/0 0/0 0/0

ROC3 0/0 0/0 0/0 0/0 0/0

ROC4 0/0 2/0 0/0 0/0 0/0

ROC5 0/0 0/0 0/0 0/0 0/0

ROC6 0/0 0/0 0/0 0/0 0/0

ROC7 0/0 0/0 0/0 0/0 0/0

DEVICE READY FOR SHIPPING

Shipped on date 2007-02-02

Plaquette assigned to panel P3L_016
