![[IMAGE] of](P_2x4B_155_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_155_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Bolla Gino on date 2/15/2007
| Part | ID |
|---|---|
| BBM | BBM_155-2x4B |
| VHDI | 2x4_463 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W29_X64K5ST | 40C |
| ROC1 | W29_X64K5ST | 40A |
| ROC2 | W29_X64K5ST | 58C |
| ROC3 | W29_X64K5ST | 58A |
| ROC4 | W29_X64K5ST | 38A |
| ROC5 | W29_X64K5ST | 38B |
| ROC6 | W29_X64K5ST | 38D |
| ROC7 | W29_X64K5ST | 39A |
Inspected by Lockwood Gale on date 2/27/2007
| LR_dev | 0.054 |
| LL_dev | 0.067 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No problems. |
PLAQUETTE made READY for ENCAPSULATION on 2/27/2007 by Lockwood Gale
PLAQUETTE encapsulated on 3/1/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/1/2007 by Ozhan Koybasi
P_2x4B_155_Aon 3/2/2007 12:28 PM
P_2x4B_155_Aon 3/2/2007 12:28 PM
PLAQUETTE TESTED on 2007-03-02 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 150 | 146 | 132 | 146 | 140 | 132 | 136 | 148 | |
| Vana | 135 | 143 | 141 | 137 | 122 | 135 | 142 | 143 | |
| Cal_Del | 66 | 80 | 96 | 93 | 81 | 88 | 84 | 69 | |
| Vthrs_Comp | 77 | 76 | 75 | 77 | 72 | 68 | 89 | 86 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_155_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_155_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_155_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_155_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_155_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_155_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 105 | 90 | 95 | 95 | 160 | 110 | 85 | 115 |
| Vsf | 140 | 145 | 140 | 140 | 135 | 140 | 145 | 140 |
| VoffsetOp | 95 | 90 | 85 | 105 | 70 | 100 | 95 | 125 |
| VIbias_PH | 100 | 100 | 100 | 105 | 95 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x4B_155_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_155_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
