![[IMAGE] of](P_2x4B_141_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_141_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 52 V |
| Operational Voltage 92 V |
Parts committed by Bolla Gino on date 3/19/2007
| Part | ID |
|---|---|
| BBM | BBM_141-2x4B |
| VHDI | 2x4_483 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W36_XD4K3LT | 48C |
| ROC1 | W36_XD4K3LT | 48B |
| ROC2 | W36_XD4K3LT | 47C |
| ROC3 | W36_XD4K3LT | 47B |
| ROC4 | W36_XD4K3LT | 54C |
| ROC5 | W36_XD4K3LT | 65C |
| ROC6 | W36_XD4K3LT | 66A |
| ROC7 | W36_XD4K3LT | 67B |
Inspected by Lockwood Gale on date 3/27/2007
| LR_dev | 0.065 |
| LL_dev | 0.026 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 3/27/2007 by Lockwood Gale
PLAQUETTE encapsulated on 3/28/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/28/2007 by Ozhan Koybasi
P_2x4B_141_Aon 3/29/2007 12:13 PM
P_2x4B_141_Aon 3/29/2007 12:13 PM
PLAQUETTE TESTED on 2007-03-29 by Joseph Clampitt
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 138 | 130 | 144 | 138 | 138 | 140 | 144 | 146 | |
| Vana | 134 | 125 | 147 | 116 | 125 | 120 | 133 | 140 | |
| Cal_Del | 92 | 103 | 65 | 82 | 89 | 96 | 88 | 75 | |
| Vthrs_Comp | 75 | 69 | 81 | 72 | 76 | 76 | 86 | 93 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 4 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 4 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_141_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_141_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_141_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_141_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_141_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_141_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 85 | 135 | 100 | 135 | 165 | 120 | 120 | 125 |
| Vsf | 140 | 140 | 145 | 135 | 140 | 140 | 140 | 145 |
| VoffsetOp | 80 | 75 | 105 | 60 | 65 | 80 | 80 | 90 |
| VIbias_PH | 100 | 100 | 100 | 100 | 100 | 95 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x4B_141_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_141_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
