| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_122_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 44 V |
| Operational Voltage 84 V |
Parts committed by Bolla Gino on date 5/22/2007
| Part | ID |
|---|---|
| BBM | BBM_122-2x4B |
| VHDI | 2x4_706 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | KMNG2DT | 23C |
| ROC1 | KMNG2DT | 23A |
| ROC2 | KMNG2DT | 13C |
| ROC3 | KMNG2DT | 13A |
| ROC4 | KMNG2DT | 22D |
| ROC5 | KMNG2DT | 13B |
| ROC6 | KMNG2DT | 53C |
| ROC7 | KMNG2DT | 62A |
Inspected by Lockwood Gale on date 6/4/2007
| LR_dev | 0.055 |
| LL_dev | 0.067 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | Assembled at HALF-PRESSURE. No assembly problems. ROC 5, Ch 34,35,1, ROC 4, Ch 1 No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 6/4/2007 by Lockwood Gale
PLAQUETTE encapsulated on 6/4/2007 by Kozak Brian
PLAQUETTE made READY for testing on 6/4/2007 by Kozak Brian
P_2x4B_122_Con 6/5/2007 9:30 AM
P_2x4B_122_C-1on 6/5/2007 10:13 AM
P_2x4B_122_C-1on 6/5/2007 10:13 AM
PLAQUETTE TESTED on 2007-06-05 by Emily Grace
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 154 | 160 | 164 | 144 | 150 | 160 | 166 | 140 | |
| Vana | 145 | 129 | 126 | 133 | 135 | 138 | 143 | 122 | |
| Cal_Del | 69 | 94 | 77 | 81 | 80 | 83 | 78 | 84 | |
| Vthrs_Comp | 87 | 78 | 84 | 80 | 74 | 77 | 91 | 75 | |
| Unbumped | 3 | 0 | 0 | 0 | 0 | 0 | 1 | 119 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 3 | 0 | 0 | 0 | 0 | 0 | 1 | 119 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_122_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_122_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_122_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_122_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_122_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_122_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 90 | 105 | 120 | 115 | 95 | 95 | 100 | 135 |
| Vsf | 145 | 140 | 140 | 140 | 140 | 140 | 145 | 135 |
| VoffsetOp | 85 | 90 | 95 | 80 | 95 | 80 | 115 | 70 |
| VIbias_PH | 105 | 100 | 105 | 95 | 100 | 105 | 95 | 100 |
Noise MAP at VMAX
![[IMAGE] of](P_2x4B_122_C-1-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_122_C-1-580-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_2x4B_122_C-1-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_122_C-1-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
