Sensor: S_2x4B_11, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC	ROC wafer	Label
ROC0	W30_X74K5RT	20B
ROC1	W30_X74K5RT	20A
ROC2	W30_X74K5RT	39D
ROC3	W30_X74K5RT	39C
ROC4	W30_X74K5RT	16B
ROC5	W30_X74K5RT	16C
ROC6	W30_X74K5RT	16D
ROC7	W30_X74K5RT	17C

FIXED (not measured) Depletion Voltage is -50 and FIXED (not measured) suggested operational voltage is -150

Ibias_DAC, Ibias_DAC Data	142	142	138	144	138	144	124	122
Vana, VanaData	128	137	126	132	129	135	123	127
TestDdata ,TestD Plots	0	0	0	0	0	0	1	5
LightData ,Light Plots	0	0	0	0	0	0	0	0
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD

Noise MAP

Efficiency MAP

ROC0 NOISE			MEAN = 5.354594 SIGMA = 0.433225
ROC1 NOISE			MEAN = 4.616522 SIGMA = 0.377331
ROC2 NOISE			MEAN = 4.777273 SIGMA = 0.374176
ROC3 NOISE			MEAN = 5.217376 SIGMA = 0.409909
ROC4 NOISE			MEAN = 4.758286 SIGMA = 0.403114
ROC5 NOISE			MEAN = 4.140267 SIGMA = 0.329456
ROC6 NOISE			MEAN = 4.075935 SIGMA = 0.307163
ROC7 NOISE			MEAN = 4.543074 SIGMA = 0.347815

Comment (if any): OK.

P_2x4B_114_A.html,

End testing time: 11:45 AM
