![[IMAGE] of](P_2x4B_105_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_105_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Arndt Kirk on date 4/5/2007
| Part | ID |
|---|---|
| BBM | BBM_105-2x4B |
| VHDI | 2x4_497 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XW4KFXT | 65C |
| ROC1 | XW4KFXT | 64D |
| ROC2 | XW4KFXT | 68C |
| ROC3 | XW4KFXT | 61A |
| ROC4 | XW4KFXT | 58B |
| ROC5 | XW4KFXT | 57A |
| ROC6 | XW4KFXT | 56A |
| ROC7 | XW4KFXT | 54A |
Inspected by Lockwood Gale on date 4/9/2007
| LR_dev | 0.042 |
| LL_dev | 0.036 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. ROC 3 ch 21,22,23, 2 attempts, No wire bonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 4/9/2007 by Lockwood Gale
PLAQUETTE encapsulated on 4/9/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 4/9/2007 by Ozhan Koybasi
P_2x4B_105_Con 4/11/2007 9:42 AM
P_2x4B_105_Con 4/11/2007 9:42 AM
P_2x4B_105_C-1on 4/11/2007 10:10 AM
P_2x4B_105_C-1on 4/11/2007 10:10 AM
PLAQUETTE TESTED on 2007-04-11 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 138 | 130 | 150 | 130 | 148 | 128 | 132 | 134 | |
| Vana | 114 | 124 | 144 | 141 | 143 | 138 | 124 | 117 | |
| Cal_Del | 90 | 80 | 78 | 89 | 79 | 90 | 87 | 75 | |
| Vthrs_Comp | 70 | 78 | 87 | 78 | 88 | 75 | 70 | 73 | |
| Unbumped | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 1 | |
| Dead | 0 | 29 | 0 | 0 | 1 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 1 | 29 | 0 | 0 | 1 | 0 | 0 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_105_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_105_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_105_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_105_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_105_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_105_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 155 | 145 | 95 | 95 | 115 | 105 | 130 | 155 |
| Vsf | 130 | 135 | 145 | 145 | 140 | 140 | 140 | 135 |
| VoffsetOp | 65 | 55 | 115 | 85 | 95 | 85 | 60 | 65 |
| VIbias_PH | 100 | 100 | 100 | 100 | 100 | 95 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x4B_105_C-1-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x4B_105_C-1-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
