![[IMAGE] of](P_2x4B_089_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_089_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_089-2x4B |
| VHDI | 2x4_532 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XI4K3GT | 44D |
| ROC1 | XI4K3GT | 36A |
| ROC2 | XI4K3GT | 35B |
| ROC3 | XI4K3GT | 39D |
| ROC4 | XI4K3GT | 33A |
| ROC5 | XI4K3GT | 32B |
| ROC6 | XI4K3GT | 32A |
| ROC7 | XI4K3GT | 42D |
Inspected by Arndt Kirk on date 2006-08-14
| LR_dev | 0.027 |
| LL_dev | 0.033 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-08-14 by Arndt Kirk
PLAQUETTE TESTED on 2006-08-15 by Petra Merkel
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 153 | 153 | 147 | 173 | 148 | 140 | 144 | 147 | |
| Vana | 135 | 130 | 127 | 139 | 134 | 127 | 122 | 120 | |
| Cal_Del | 92 | 88 | 89 | 71 | 91 | 94 | 81 | 75 | |
| Vthrs_Comp | 79 | 74 | 73 | 85 | 80 | 67 | 70 | 76 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_089_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_089_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_089_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_089_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_089_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_089_Cno-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-08-17
