P_2x4B_073

P_2x4B_073_A

Parts committed by Bolla Gino on date 5/22/2007

Part	ID
BBM	BBM_073-2x4B
VHDI	2x4_678

ROC ROC wafer Label

ROC0 W45_D3LQFLT 54C

ROC1 W45_D3LQFLT 54B

ROC2 W45_D3LQFLT 54A

ROC3 W45_D3LQFLT 53D

ROC4 W45_D3LQFLT 34C

ROC5 W45_D3LQFLT 35B

ROC6 W45_D3LQFLT 36C

ROC7 W45_D3LQFLT 37A

ROC	ROC wafer	Label
ROC0	W45_D3LQFLT	54C
ROC1	W45_D3LQFLT	54B
ROC2	W45_D3LQFLT	54A
ROC3	W45_D3LQFLT	53D
ROC4	W45_D3LQFLT	34C
ROC5	W45_D3LQFLT	35B
ROC6	W45_D3LQFLT	36C
ROC7	W45_D3LQFLT	37A

Inspected by Lockwood Gale on date 6/11/2007

LR_dev 0.060

LL_dev 0.037

PLAQUETTE GLUED with FULL PRESSURE

FINAL COMMENT by Lockwood Gale

No assembly problems. ROC 4, CH 34, 1,2,13-26, ROC 5,CH 34,35, ROC 7 23,25 No wirebonding problems.

PLAQUETTE made READY for ENCAPSULATION on 6/11/2007 by Lockwood Gale

PLAQUETTE encapsulated on 6/11/2007 by Kozak Brian

PLAQUETTE made READY for testing on 6/11/2007 by Kozak Brian

P_2x4B_073_Aon 6/12/2007 11:13 AM

P_2x4B_073_A-1on 6/12/2007 11:14 AM

PLAQUETTE TESTED on 2007-06-12 by Emily Grace

IV_XML-File

Maximum Voltage 160 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	160	162	150	170	150	166	164	158
Vana	138	153	137	146	156	155	141	151
Cal_Del	79	94	86	81	71	75	94	78
Vthrs_Comp	89	86	85	91	91	92	84	89
Unbumped	0	1	0	0	0	0	1	0
Dead	1	75	71	1	0	52	13	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	1	76	71	1	0	52	14	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

EXTRA DACs for NOISE

VHldDe	115	95	90	95	95	100	115	95
Vsf	140	145	145	150	155	160	140	150
VoffsetOp	110	110	100	105	120	120	80	115
VIbias_PH	100	100	100	105	105	100	105	100

Noise MAP at VMAX

Efficiency MAP

Noise MAP at -200 V

Efficiency MAP

PLAQUETTE READY TO BE SHIPPED

PLAQUETTE TESTED on 2007-06-12 by Emily Grace

IV_XML-File

Maximum Voltage 160 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	160	162	150	170	150	166	164	158
Vana	138	153	137	146	156	155	141	151
Cal_Del	79	94	86	81	71	75	94	78
Vthrs_Comp	89	86	85	91	91	92	84	89
Unbumped	0	1	0	0	0	0	1	0
Dead	1	75	71	1	0	52	13	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	1	76	71	1	0	52	14	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

EXTRA DACs for NOISE

VHldDe	115	95	90	95	95	100	115	95
Vsf	140	145	145	150	155	160	140	150
VoffsetOp	110	110	100	105	120	120	80	115
VIbias_PH	100	100	100	105	105	100	105	100

Noise MAP at VMAX

Efficiency MAP

Noise MAP at -200 V

Efficiency MAP

PLAQUETTE READY TO BE SHIPPED

Shipped on date 2007-06-14
