P_2x4B_048

P_2x4B_048_C

Parts committed by Bolla Gino on date 2/16/2007

Part	ID
BBM	BBM_048-2x4B
VHDI	2x4_471

ROC ROC wafer Label

ROC0 XG4KFCT 43B

ROC1 XG4KFCT 43A

ROC2 XG4KFCT 41B

ROC3 XG4KFCT 41A

ROC4 XG4KFCT 48D

ROC5 XG4KFCT 49D

ROC6 XG4KFCT 40A

ROC7 XG4KFCT 40B

ROC	ROC wafer	Label
ROC0	XG4KFCT	43B
ROC1	XG4KFCT	43A
ROC2	XG4KFCT	41B
ROC3	XG4KFCT	41A
ROC4	XG4KFCT	48D
ROC5	XG4KFCT	49D
ROC6	XG4KFCT	40A
ROC7	XG4KFCT	40B

Inspected by Arndt Kirk on date 2/23/2007

LR_dev 0.064

LL_dev 0.059

FINAL COMMENT by Arndt Kirk No assembly problems. All wies OK. ROC4 chn 34,35; ROC5 chn 32,33 required multiple attempts to bond VHDI pads.

PLAQUETTE made READY for ENCAPSULATION on 2/23/2007 by Arndt Kirk

PLAQUETTE encapsulated on 2/28/2007 by Ozhan Koybasi

PLAQUETTE made READY for testing on 2/28/2007 by Ozhan Koybasi

P_2x4B_048_Con 3/2/2007 12:01 PM

PLAQUETTE TESTED on 2007-03-02 by Cameron McKinney

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 48 V

Operational Voltage 88 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	146	130	148	140	118	142	140	128
Vana	147	135	144	134	129	141	132	111
Cal_Del	78	90	78	92	97	65	69	88
Vthrs_Comp	81	72	90	81	73	92	80	63
Unbumped	0	0	1	0	0	0	0	48
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	1	0	0	0	0	48

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File
