![[IMAGE] of](P_2x4B_006_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x4B_006_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_006-2x4B |
| VHDI | 2x4_260 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | X74JP0T | 65B |
| ROC1 | X74JP0T | 64D |
| ROC2 | X74JP0T | 63D |
| ROC3 | X74JP0T | 63C |
| ROC4 | X74JP0T | 45A |
| ROC5 | X74JP0T | 45B |
| ROC6 | X74JP0T | 45D |
| ROC7 | X74JP0T | 46A |
Inspected by Arndt Kirk on date 2006-06-27
| LR_dev | 0.043 |
| LL_dev | 0.047 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-06-27 by Arndt Kirk
PLAQUETTE TESTED on 2006-6-28 by Petra Merkel
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | |
| Ibias_DAC | 168 | 160 | 171 | 186 | 169 | 170 | 149 | 169 | |
| Vana | 121 | 120 | 132 | 134 | 138 | 133 | 111 | 131 | |
| Cal_Del | 89 | 81 | 79 | 88 | 71 | 72 | 86 | 87 | |
| Vthrs_Comp | 78 | 76 | 86 | 84 | 87 | 84 | 75 | 75 | |
| Unbumped | 0 | 0 | 3 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 3 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x4B_006_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x4B_006_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x4B_006_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x4B_006_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x4B_006_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x4B_006_Ano-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-07-10
