| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3T_162_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Arndt Kirk on date 5/1/2007
| Part | ID |
|---|---|
| BBM | BBM_162-2x3T |
| VHDI | 2x3_410 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | KNN0GDT | 03D |
| ROC1 | KNN0GDT | 03B |
| ROC2 | KNN0GDT | 12B |
| ROC3 | KNN0GDT | 32C |
| ROC4 | KNN0GDT | 03C |
| ROC5 | KNN0GDT | 12A |
Inspected by Lockwood Gale on date 5/4/2007
| LR_dev | 0.077 |
| LL_dev | 0.070 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | Assembled at HALF-PRESSURE. No assembly problems. No wirebonding propblems. |
PLAQUETTE made READY for ENCAPSULATION on 5/4/2007 by Lockwood Gale
PLAQUETTE encapsulated on 5/4/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 5/4/2007 by Ozhan Koybasi
P_2x3T_162_Con 5/7/2007 4:19 PM
P_2x3T_162_Con 5/7/2007 4:19 PM
PLAQUETTE TESTED on 2007-05-07 by mia tosi
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 142 | 144 | 134 | 146 | 146 | 134 | |
| Vana | 125 | 144 | 127 | 139 | 133 | 122 | |
| Cal_Del | 79 | 77 | 72 | 73 | 78 | 73 | |
| Vthrs_Comp | 74 | 76 | 74 | 85 | 79 | 75 | |
| Unbumped | 0 | 1 | 3 | 0 | 1 | 0 | |
| Dead | 2 | 1 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 2 | 2 | 3 | 0 | 1 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3T_162_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3T_162_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3T_162_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3T_162_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3T_162_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3T_162_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 125 | 95 | 105 | 120 | 125 | 130 |
| Vsf | 140 | 145 | 140 | 140 | 145 | 140 |
| VoffsetOp | 70 | 90 | 85 | 85 | 80 | 70 |
| VIbias_PH | 100 | 105 | 100 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x3T_162_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3T_162_C-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
