P_2x3T_157

P_2x3T_157_A

Parts committed by Bolla Gino on date 12/15/2006

Part	ID
BBM	BBM_157-2x3T
VHDI	2x3_217

ROC ROC wafer Label

ROC0 W21_XA4KFIT 32C

ROC1 W21_XA4KFIT 32B

ROC2 W21_XA4KFIT 32A

ROC3 W21_XA4KFIT 27C

ROC4 W21_XA4KFIT 27D

ROC5 W21_XA4KFIT 28B

ROC	ROC wafer	Label
ROC0	W21_XA4KFIT	32C
ROC1	W21_XA4KFIT	32B
ROC2	W21_XA4KFIT	32A
ROC3	W21_XA4KFIT	27C
ROC4	W21_XA4KFIT	27D
ROC5	W21_XA4KFIT	28B

Inspected by Lockwood Gale on date 12/19/2006

LR_dev 0.043

LL_dev 0.054

FINAL COMMENT by Lockwood Gale No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 12/19/2006 by Lockwood Gale

P_2x3T_157_Aon 12/19/2006 3:12 PM

PLAQUETTE TESTED on 2006-12-19 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 46 V

Operational Voltage 86 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	144	140	142	130	136	144
Vana	135	127	122	115	123	151
Cal_Del	87	82	81	87	86	83
Vthrs_Comp	66	79	70	72	71	87
Unbumped	0	0	0	0	0	0
Dead	0	0	6	0	0	0
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	0	0	6	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2007-01-05
