Sensor: S_2x3T_15, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W21_XA4KFIT | 32C |
| ROC1 | W21_XA4KFIT | 32B |
| ROC2 | W21_XA4KFIT | 32A |
| ROC3 | W21_XA4KFIT | 27C |
| ROC4 | W21_XA4KFIT | 27D |
| ROC5 | W21_XA4KFIT | 28B |
| Ibias_DAC, Ibias_DAC Data | 144 | 140 | 142 | 130 | 136 | 144 |
| Vana, VanaData | 135 | 127 | 122 | 115 | 123 | 151 |
| CalDelData and plots | 87 | 82 | 81 | 87 | 86 | 83 |
| VthrCompData and plots | 66 | 79 | 70 | 72 | 71 | 87 | Depletion Voltage is -46 and suggested operational voltage is -86
| TestDdata ,TestD Plots | 0 | 0 | 6 | 0 | 0 | 0 |
| LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Comment (if any): 6 dead channels
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 3:25 PM
