P_2x3T_118

P_2x3T_118_A

Parts committed by Bolla Gino on date 11/20/2006

Part	ID
BBM	BBM_118-2x3T
VHDI	2x3_205

ROC ROC wafer Label

ROC0 W21_XA4KFIT 51A

ROC1 W21_XA4KFIT 68D

ROC2 W21_XA4KFIT 68B

ROC3 W21_XA4KFIT 45D

ROC4 W21_XA4KFIT 46D

ROC5 W21_XA4KFIT 47A

ROC	ROC wafer	Label
ROC0	W21_XA4KFIT	51A
ROC1	W21_XA4KFIT	68D
ROC2	W21_XA4KFIT	68B
ROC3	W21_XA4KFIT	45D
ROC4	W21_XA4KFIT	46D
ROC5	W21_XA4KFIT	47A

Inspected by Lockwood Gale on date 11/27/2006

LR_dev 0.030

LL_dev 0.033

FINAL COMMENT by Lockwood Gale No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/27/2006 by Lockwood Gale

P_2x3T_118_Aon 11/27/2006 1:47 PM

PLAQUETTE TESTED on 2006-11-27 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	141	136	141	135	149	153
Vana	127	131	111	120	139	141
Cal_Del	78	75	95	93	76	73
Vthrs_Comp	77	75	65	66	85	74
Unbumped	0	0	0	0	0	0
Dead	0	0	0	0	0	0
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-29

Plaquette assigned to panel P3L_014
