P_2x3T_111

P_2x3T_111_C

Production testing

Date:8/30/2007

Operator: Joseph Clampitt

start testing time:3:25 PM

Sensor: S_2x3T_11, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 DWLQFTT 54B

ROC1 KNNGODT 43D

ROC2 DWLQFTT 64D

ROC3 DWLQFTT 54A

ROC4 DWLQFTT 66A

ROC5 DWLQFTT 63B

ROC	ROC wafer	Label
ROC0	DWLQFTT	54B
ROC1	KNNGODT	43D
ROC2	DWLQFTT	64D
ROC3	DWLQFTT	54A
ROC4	DWLQFTT	66A
ROC5	DWLQFTT	63B

This plaquette was reworked. Old results here

Inspected by Arndt Kirk on date 8/28/2007

LR_dev 0.011

LL_dev 0.008

PLAQUETTE GLUED with HALF PRESSURE

FINAL COMMENT by Arndt Kirk

Assembled at HALF-PRESSURE. No assembly problems. ROC0 ch 24,33,35; ROC1 ch 1; ROC2 ch 35 required multiple bond attempts to stick bonds to VHDI pads. No other wirebond problems. All wirebonds appear OK.

PLAQUETTE made READY for ENCAPSULATION on 8/28/2007 by Arndt Kirk

PLAQUETTE encapsulated on 8/28/2007 by Ozhan Koybasi

PLAQUETTE made READY for testing on 8/28/2007 by Ozhan Koybasi

P_2x3T_111_Con 8/30/2007 3:25 PM

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data	156	162	156	144	164	144
Vana, VanaData	142	121	159	139	150	137
CalDelData and plots	85	78	88	96	79	86
VthrCompData and plots	87	77	91	79	91	86
TestDdata ,TestD Plots	1	74	0	46	87	20
LightData ,Light Plots	0	2	9	73	548	30
Pass/Fail TestD	GOOD	BAD	GOOD	BAD	BAD	GOOD
Pass/Fail LIGHT	GOOD	GOOD	GOOD	BAD	BAD	GOOD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	90	150	95	95	100	115
Vsf	140	140	155	140	150	140
VoffsetOp	95	55	110	85	115	90
VIbias_PH	105	105	100	100	100	105

ROC0 NOISE			MEAN = 4.495854 SIGMA = 0.336003
ROC1 NOISE			MEAN = 4.583519 SIGMA = 0.383533
ROC2 NOISE			MEAN = 4.423826 SIGMA = 0.367764
ROC3 NOISE			MEAN = 4.421903 SIGMA = 0.347344
ROC4 NOISE			MEAN = 3.954736 SIGMA = 0.319468
ROC5 NOISE			MEAN = 4.462018 SIGMA = 0.346736

Comment (if any): Many unbumped pixels on ROCs 3, 4, and 5. Otherwise good.

This Device have been tested 0Times prior to this one and here are the links to the previous tests:

End testing time: 5:15 PM
