P_2x3T_086

P_2x3T_086_A

Parts committed by Bolla Gino on date 11/13/2006

Part	ID
BBM	BBM_086-2x3T
VHDI	2x3_376

ROC ROC wafer Label

ROC0 W20_XP4K3AT 28C

ROC1 W20_XP4K3AT 68A

ROC2 W20_XP4K3AT 27C

ROC3 W20_XP4K3AT 34A

ROC4 W20_XP4K3AT 34B

ROC5 W20_XP4K3AT 34D

ROC	ROC wafer	Label
ROC0	W20_XP4K3AT	28C
ROC1	W20_XP4K3AT	68A
ROC2	W20_XP4K3AT	27C
ROC3	W20_XP4K3AT	34A
ROC4	W20_XP4K3AT	34B
ROC5	W20_XP4K3AT	34D

Inspected by Graves Durand on date 11/15/2006

LR_dev 0.000

LL_dev 0.006

FINAL COMMENT by Graves Durand No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/15/2006 by Graves Durand

PLAQUETTE TESTED on 2006-11-15 by Isaac Childres

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 42 V

Operational Voltage 82 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5
Ibias_DAC	143	121	140	136	137	132
Vana	131	125	126	131	128	143
Cal_Del	88	92	83	89	85	85
Vthrs_Comp	79	75	66	69	71	85
Unbumped	0	0	0	0	0	0
Dead	0	0	0	0	0	0
Noisy	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

P_2x3T_086_A-1on 11/17/2006 4:35 PM

Shipped on date 2006-11-20

Plaquette assigned to panel P3R_005
