P3R_005
Unbumped pixels are red, dead are black, noisy are yellow, and undecoded are blue
Plaquette
Position
Purdue Map
FNAL Plaq. Map
FNAL Panel Map
P_2x5_043_A
3
P_2x4B_086_A
2
P_2x3T_086_A
1
Panel assembly comments
8Feb07/Sudhir: This panel is PTA and light tested after encapsulation
Overall panel grade:
A1
