![[IMAGE] of](P_2x3T_067_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 570 V |
![[IMAGE] of](P_2x3T_067_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Bolla Gino on date 2/8/2007
| Part | ID |
|---|---|
| BBM | BBM_067-2x3T |
| VHDI | 2x3_447 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W29_X64K5ST | 17A |
| ROC1 | W29_X64K5ST | 16D |
| ROC2 | W29_X64K5ST | 16C |
| ROC3 | W33_XC4K5LT | 64D |
| ROC4 | W33_XC4K5LT | 65B |
| ROC5 | W33_XC4K5LT | 65C |
Inspected by Lockwood Gale on date 2/16/2007
| LR_dev | 0.018 |
| LL_dev | 0.058 |
| FINAL COMMENT by Lockwood Gale | No assembly problems Roc 2 channel 35, roc 4 channel 35, two attempts to bond. no other wirebonding problems. |
PLAQUETTE made READY for testing on 2/16/2007 by Lockwood Gale
PLAQUETTE encapsulated on 2/20/2007 by Arndt Kirk
P_2x3T_067_Aon 2/20/2007 11:46 AM
P_2x3T_067_Aon 2/20/2007 11:46 AM
PLAQUETTE TESTED on 2007-02-20 by Joseph Clampitt
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 134 | 126 | 140 | 132 | 130 | 134 | |
| Vana | 137 | 125 | 134 | 145 | 123 | 122 | |
| Cal_Del | 78 | 73 | 66 | 75 | 95 | 85 | |
| Vthrs_Comp | 79 | 74 | 80 | 80 | 72 | 66 | |
| Unbumped | 0 | 0 | 0 | 0 | 3 | 0 | |
| Dead | 0 | 0 | 0 | 1 | 0 | 1 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 1 | 3 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3T_067_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3T_067_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3T_067_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3T_067_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3T_067_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3T_067_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 105 | 135 | 115 | 95 | 130 | 120 |
| Vsf | 140 | 135 | 135 | 140 | 140 | 135 |
| VoffsetOp | 75 | 70 | 80 | 85 | 90 | 55 |
| VIbias_PH | 105 | 105 | 100 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x3T_067_A-100-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3T_067_A-100-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 105 | 135 | 115 | 95 | 130 | 120 |
| Vsf | 140 | 135 | 135 | 140 | 140 | 135 |
| VoffsetOp | 75 | 70 | 80 | 85 | 90 | 55 |
| VIbias_PH | 105 | 105 | 100 | 100 | 100 | 100 |
PLAQUETTE READY TO BE SHIPPED
