Sensor: S_2x3T_03, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | W55_D3LQE4T | 54C |
ROC1 | W55_D3LQE4T | 53B |
ROC2 | W55_D3LQE4T | 53A |
ROC3 | W55_D3LQE4T | 35B |
ROC4 | W55_D3LQE4T | 35C |
ROC5 | W55_D3LQE4T | 36A |
Ibias_DAC, Ibias_DAC Data | 160 | 168 | 158 | 148 | 156 | 148 |
Vana, VanaData | 154 | 153 | 150 | 141 | 160 | 151 |
CalDelData and plots | 74 | 73 | 99 | 105 | 71 | 74 |
VthrCompData and plots | 93 | 93 | 87 | 72 | 92 | 85 | Depletion Voltage is -46 and suggested operational voltage is -86
TestDdata ,TestD Plots | 1 | 0 | 2 | 0 | 0 | 1 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD | GOOD |
Noise MAP at VMAX
Efficiency MAP
EXTRA DACs for NOISE
VHldDe | 90 | 105 | 90 | 85 | 95 | 90 |
Vsf | 150 | 145 | 150 | 145 | 165 | 150 |
VoffsetOp | 110 | 100 | 100 | 90 | 100 | 110 |
VIbias_PH | 100 | 105 | 100 | 100 | 95 | 95 |
Comment (if any):
This Device have been tested 1Times prior to this one and here are the links to the previous tests:End testing time: 12:31 PM
