![[IMAGE] of](P_2x3B_182_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3B_182_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Bolla Gino on date 1/30/2007
| Part | ID |
|---|---|
| BBM | BBM_182-2x3B |
| VHDI | 2x3_436 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W28_X54K5TT | 13A |
| ROC1 | W28_X54K5TT | 12D |
| ROC2 | W28_X54K5TT | 12C |
| ROC3 | W29_X64K5ST | 66C |
| ROC4 | W29_X64K5ST | 67B |
| ROC5 | W29_X64K5ST | 67C |
Inspected by Lockwood Gale on date 2/14/2007
| LR_dev | 0.049 |
| LL_dev | 0.045 |
| FINAL COMMENT by Lockwood Gale | No assembly problem. No wirebonding problems. |
PLAQUETTE made READY for testing on 2/14/2007 by Lockwood Gale
P_2x3B_182_Aon 2/16/2007 11:57 AM
P_2x3B_182_Aon 2/16/2007 11:57 AM
PLAQUETTE TESTED on 2007-02-16 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 142 | 134 | 124 | 144 | 138 | 128 | |
| Vana | 124 | 126 | 127 | 132 | 133 | 128 | |
| Cal_Del | 82 | 79 | 99 | 80 | 84 | 76 | |
| Vthrs_Comp | 73 | 67 | 63 | 81 | 70 | 88 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_182_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_182_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_182_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_182_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_182_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_182_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 140 | 115 | 120 | 115 | 95 | 125 |
| Vsf | 135 | 140 | 140 | 140 | 140 | 140 |
| VoffsetOp | 85 | 85 | 75 | 100 | 115 | 90 |
| VIbias_PH | 105 | 100 | 100 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x3B_182_A-100-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_182_A-100-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 140 | 115 | 120 | 115 | 95 | 125 |
| Vsf | 135 | 140 | 140 | 140 | 140 | 140 |
| VoffsetOp | 85 | 85 | 75 | 100 | 115 | 90 |
| VIbias_PH | 105 | 100 | 100 | 100 | 100 | 100 |
PLAQUETTE READY TO BE POTTED
