P_2x3B_165

P_2x3B_165_C-1

Production testing

Date:5/10/2007

Operator: mia tosi

start testing time:12:56 PM

Sensor: S_2x3B_16, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 KFNG13T 12C

ROC1 KFNG13T 21D

ROC2 KFNG13T 03C

ROC3 KFNG13T 22A

ROC4 KFNG13T 42A

ROC5 KFNG13T 42B

ROC	ROC wafer	Label
ROC0	KFNG13T	12C
ROC1	KFNG13T	21D
ROC2	KFNG13T	03C
ROC3	KFNG13T	22A
ROC4	KFNG13T	42A
ROC5	KFNG13T	42B

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data 160 152 144 146 172 166

Vana, VanaData 139 130 126 122 133 142

CalDelData and plots 74 78 92 73 82 65

VthrCompData and plots 86 72 71 84 74 78

TestDdata ,TestD Plots 0 0 1 0 0 2

LightData ,Light Plots 0 0 0 0 0 5

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT GOOD GOOD GOOD GOOD GOOD GOOD

Noise MAP

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	95	115	105	140	125	95
Vsf	145	140	140	135	140	140
VoffsetOp	90	90	70	80	85	85
VIbias_PH	100	100	105	100	100	105

ROC0 NOISE			MEAN = 3.943341 SIGMA = 0.325945
ROC1 NOISE			MEAN = 3.918483 SIGMA = 0.308871
ROC2 NOISE			MEAN = 5.109360 SIGMA = 0.406255
ROC3 NOISE			MEAN = 4.279045 SIGMA = 0.349212
ROC4 NOISE			MEAN = 3.820724 SIGMA = 0.292173
ROC5 NOISE			MEAN = 4.584079 SIGMA = 0.367787

Comment (if any): good [look @ROC5 corner]

This Device have been tested 1Times prior to this one and here are the links to the previous tests:

P_2x3B_165_C.html,

End testing time: 1:16 PM
