![[IMAGE] of](P_2x3B_163_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3B_163_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 42 V |
| Operational Voltage 82 V |
Parts committed by Arndt Kirk on date 5/1/2007
| Part | ID |
|---|---|
| BBM | BBM_163-2x3B |
| VHDI | 2x3_413 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | KNN0GDT | 21B |
| ROC1 | KNN0GDT | 52B |
| ROC2 | KNN0GDT | 62A |
| ROC3 | KNN0GDT | 52D |
| ROC4 | KNN0GDT | 11B |
| ROC5 | KNN0GDT | 11C |
Inspected by Arndt Kirk on date 5/8/2007
| LR_dev | 0.012 |
| LL_dev | 0.030 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Arndt Kirk | Assembled at HALF-PRESSURE. No assembly problems. No wirebond problem. |
PLAQUETTE made READY for ENCAPSULATION on 5/8/2007 by Arndt Kirk
PLAQUETTE encapsulated on 5/8/2007 by Ortiz Jason
PLAQUETTE made READY for testing on 5/8/2007 by Ortiz Jason
P_2x3B_163_Con 5/8/2007 11:32 PM
P_2x3B_163_Con 5/8/2007 11:32 PM
PLAQUETTE TESTED on 2007-05-08 by Petra Merkel
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 138 | 130 | 154 | 140 | 150 | 148 | |
| Vana | 145 | 121 | 139 | 131 | 127 | 150 | |
| Cal_Del | 73 | 93 | 71 | 81 | 84 | 65 | |
| Vthrs_Comp | 84 | 66 | 82 | 83 | 73 | 92 | |
| Unbumped | 0 | 0 | 0 | 1 | 0 | 156 | |
| Dead | 1 | 0 | 1 | 0 | 0 | 1 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 1 | 0 | 1 | 1 | 0 | 157 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_163_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_163_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_163_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_163_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_163_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_163_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 100 | 135 | 95 | 115 | 125 | 95 |
| Vsf | 145 | 135 | 140 | 140 | 135 | 145 |
| VoffsetOp | 90 | 65 | 95 | 85 | 75 | 100 |
| VIbias_PH | 105 | 95 | 105 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x3B_163_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_163_C-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
