P_2x3B_053

P_2x3B_053_A-1

Production testing

Date:11/15/2007

Operator: Ozhan Koybasi

start testing time:10:21 PM

Sensor: S_2x3B_05, Data for leakage current measurement , and plot on overall it is a GOOD sensor

ROC ROC wafer Label

ROC0 W52_DOLQC8T 40B

ROC1 W52_DOLQC8T 40A

ROC2 W52_DOLQC8T 58C

ROC3 W52_DOLQC8T 35B

ROC4 W52_DOLQC8T 35C

ROC5 W52_DOLQC8T 36C

ROC	ROC wafer	Label
ROC0	W52_DOLQC8T	40B
ROC1	W52_DOLQC8T	40A
ROC2	W52_DOLQC8T	58C
ROC3	W52_DOLQC8T	35B
ROC4	W52_DOLQC8T	35C
ROC5	W52_DOLQC8T	36C

Depletion Voltage is -46 and suggested operational voltage is -86

Ibias_DAC, Ibias_DAC Data 154 150 156 144 146 156

Vana, VanaData 144 145 137 132 158 144

CalDelData and plots 85 86 92 90 81 79

VthrCompData and plots 81 91 84 89 90 89

TestDdata ,TestD Plots 0 5 2 0 5 1

LightData ,Light Plots 1752 2475 1114 98 1804 1481

Pass/Fail TestD GOOD GOOD GOOD GOOD GOOD GOOD

Pass/Fail LIGHT BAD BAD BAD BAD BAD BAD

Noise MAP at VMAX

Efficiency MAP

EXTRA DACs for NOISE

VHldDe	90	100	90	120	100	105
Vsf	145	145	145	140	160	145
VoffsetOp	100	115	105	100	110	115
VIbias_PH	95	100	100	105	100	100

ROC0 NOISE			MEAN = 3.977479 SIGMA = 0.300055
ROC1 NOISE			MEAN = 4.060828 SIGMA = 0.301266
ROC2 NOISE			MEAN = 4.174878 SIGMA = 0.319116
ROC3 NOISE			MEAN = 4.021679 SIGMA = 0.301570
ROC4 NOISE			MEAN = 3.953045 SIGMA = 0.307357
ROC5 NOISE			MEAN = 3.974050 SIGMA = 0.320068

Comment (if any): light testing failed

This Device have been tested 1Times prior to this one and here are the links to the previous tests:

P_2x3B_053_A.html,

End testing time: 10:49 PM

Ibias_DAC, Ibias_DAC Data	154	150	156	144	146	156
Vana, VanaData	144	145	137	132	158	144
CalDelData and plots	85	86	92	90	81	79
VthrCompData and plots	81	91	84	89	90	89
TestDdata ,TestD Plots	0	5	2	0	5	1
LightData ,Light Plots	1752	2475	1114	98	1804	1481
Pass/Fail TestD	GOOD	GOOD	GOOD	GOOD	GOOD	GOOD
Pass/Fail LIGHT	BAD	BAD	BAD	BAD	BAD	BAD
