![[IMAGE] of](P_2x3B_030_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 320 V |
![[IMAGE] of](P_2x3B_030_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 46 V |
| Operational Voltage 86 V |
Parts committed by Bolla Gino on date 4/23/2007
| Part | ID |
|---|---|
| BBM | BBM_030-2x3B |
| VHDI | 2x3_552 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W35_XH4K3HT | 14B |
| ROC1 | W35_XH4K3HT | 14A |
| ROC2 | W35_XH4K3HT | 13D |
| ROC3 | W35_XH4K3HT | 32C |
| ROC4 | W35_XH4K3HT | 33B |
| ROC5 | W35_XH4K3HT | 33C |
Inspected by Lockwood Gale on date 4/24/2007
| LR_dev | 0.035 |
| LL_dev | 0.042 |
PLAQUETTE GLUED with FULL PRESSURE
| FINAL COMMENT by Lockwood Gale | Assembled at FULL-PRESSURE. No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 4/24/2007 by Lockwood Gale
PLAQUETTE encapsulated on 4/24/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 4/24/2007 by Ozhan Koybasi
P_2x3B_030_Aon 4/26/2007 12:10 PM
P_2x3B_030_Aon 4/26/2007 12:10 PM
PLAQUETTE TESTED on 2007-04-26 by Joseph Clampitt
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 134 | 134 | 140 | 154 | 130 | 128 | |
| Vana | 124 | 117 | 132 | 140 | 138 | 127 | |
| Cal_Del | 89 | 94 | 80 | 64 | 80 | 90 | |
| Vthrs_Comp | 65 | 78 | 81 | 83 | 71 | 75 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 1 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 1 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_030_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_030_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_030_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_030_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_030_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_030_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 125 | 145 | 115 | 105 | 95 | 115 |
| Vsf | 140 | 130 | 140 | 140 | 140 | 140 |
| VoffsetOp | 80 | 80 | 80 | 125 | 70 | 60 |
| VIbias_PH | 95 | 95 | 100 | 100 | 100 | 100 |
Noise MAP
![[IMAGE] of](P_2x3B_030_A-300-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_030_A-300-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
