| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3B_021_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 44 V |
| Operational Voltage 84 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_021-2x3B |
| VHDI | 2x3_282 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XL4K3DT | 63C |
| ROC1 | XL4K3DT | 66D |
| ROC2 | XL4K3DT | 61D |
| ROC3 | XL4K3DT | 57B |
| ROC4 | XL4K3DT | 58A |
| ROC5 | XL4K3DT | 57A |
Inspected by Arndt Kirk on date 2006-07-24
| LR_dev | 0.083 |
| LL_dev | 0.052 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-07-24 by Arndt Kirk
PLAQUETTE TESTED on 2006-7-25 by Stacy Kouba
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 151 | 174 | 155 | 161 | 167 | 158 | |
| Vana | 115 | 114 | 110 | 106 | 129 | 118 | |
| Cal_Del | 107 | 108 | 84 | 111 | 83 | 97 | |
| Vthrs_Comp | 71 | 79 | 84 | 66 | 80 | 79 | |
| Unbumped | 0 | 2 | 1 | 1 | 0 | 0 | |
| Dead | 0 | 6 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 8 | 1 | 1 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_021_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_021_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_021_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_021_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_021_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_021_Cno-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-07-27
