![[IMAGE] of](P_2x3B_019_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x3B_019_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date 11/19/2007
| Part | ID |
|---|---|
| BBM | BBM_019-2x3B |
| VHDI | 2x3_750 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W53_DXLQG9T | 66A |
| ROC1 | W53_DXLQG9T | 65D |
| ROC2 | W53_DXLQG9T | 65B |
| ROC3 | W53_DXLQG9T | 46D |
| ROC4 | W53_DXLQG9T | 47C |
| ROC5 | W53_DXLQG9T | 48A |
Inspected by Lockwood Gale on date 11/27/2007
| LR_dev | 0.053 |
| LL_dev | 0.058 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | Force used to join BBM to VHDI = 2.5 kg per ROC. No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 11/27/2007 by Lockwood Gale
PLAQUETTE encapsulated on 11/28/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 11/28/2007 by Ozhan Koybasi
P_2x3B_019_Aon 11/29/2007 1:39 PM
P_2x3B_019_Aon 11/29/2007 1:39 PM
PLAQUETTE TESTED on 2007-11-29 by Gino Bolla
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | |
| Ibias_DAC | 154 | 156 | 144 | 164 | 146 | 150 | |
| Vana | 143 | 166 | 144 | 150 | 158 | 145 | |
| Cal_Del | 78 | 79 | 99 | 86 | 82 | 82 | |
| Vthrs_Comp | 91 | 91 | 75 | 88 | 91 | 86 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x3B_019_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x3B_019_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x3B_019_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x3B_019_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x3B_019_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x3B_019_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 100 | 110 | 90 | 90 | 95 | 95 |
| Vsf | 145 | 165 | 145 | 145 | 155 | 145 |
| VoffsetOp | 110 | 130 | 90 | 120 | 90 | 105 |
| VIbias_PH | 100 | 100 | 95 | 100 | 105 | 95 |
Noise MAP at VMAX
![[IMAGE] of](P_2x3B_019_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_019_A-580-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_2x3B_019_A-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x3B_019_A-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
