Sensor: S_1x5R_17, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROC | ROC wafer | Label |
---|---|---|
ROC0 | KFNG13T | 26D |
ROC1 | KFNG13T | 36A |
ROC2 | KFNG13T | 36D |
ROC3 | KFNG13T | 16B |
ROC4 | KFNG13T | 46C |
Ibias_DAC, Ibias_DAC Data | 148 | 150 | 174 | 140 | 156 |
Vana, VanaData | 133 | 129 | 135 | 127 | 135 |
CalDelData and plots | 91 | 80 | 72 | 81 | 73 |
VthrCompData and plots | 75 | 71 | 74 | 76 | 87 | Depletion Voltage is -52 and suggested operational voltage is -92
TestDdata ,TestD Plots | 0 | 0 | 0 | 0 | 0 |
LightData ,Light Plots | 0 | 0 | 0 | 0 | 0 |
Pass/Fail TestD | GOOD | GOOD | GOOD | GOOD | GOOD |
Pass/Fail LIGHT | GOOD | GOOD | GOOD | GOOD | GOOD |
Noise MAP at VMAX
Efficiency MAP
EXTRA DACs for NOISE
VHldDe | 115 | 90 | 100 | 120 | 115 |
Vsf | 145 | 140 | 140 | 135 | 140 |
VoffsetOp | 75 | 75 | 90 | 70 | 100 |
VIbias_PH | 105 | 100 | 100 | 95 | 95 |
Comment (if any):
This Device have been tested 1Times prior to this one and here are the links to the previous tests:End testing time: 1:54 PM
