![[IMAGE] of](P_1x5R_141_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x5R_141_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 52 V |
| Operational Voltage 92 V |
Parts committed by Bolla Gino on date 3/19/2007
| Part | ID |
|---|---|
| BBM | BBM_141-1x5 |
| VHDI | 1x5R_254 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W36_XD4K3LT | 45B |
| ROC1 | W36_XD4K3LT | 45A |
| ROC2 | W36_XD4K3LT | 44C |
| ROC3 | W36_XD4K3LT | 44B |
| ROC4 | W36_XD4K3LT | 44A |
Inspected by Lockwood Gale on date 3/22/2007
| LR_dev | 0.068 |
| LL_dev | 0.042 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebond problems. |
PLAQUETTE made READY for ENCAPSULATION on 3/22/2007 by Lockwood Gale
PLAQUETTE encapsulated on 3/22/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/22/2007 by Ozhan Koybasi
P_1x5R_141_Aon 3/23/2007 10:37 AM
P_1x5R_141_Aon 3/23/2007 10:37 AM
PLAQUETTE TESTED on 2007-03-23 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 124 | 126 | 134 | 140 | 132 | |
| Vana | 134 | 127 | 137 | 138 | 132 | |
| Cal_Del | 83 | 96 | 87 | 84 | 84 | |
| Vthrs_Comp | 77 | 76 | 70 | 79 | 68 | |
| Unbumped | 0 | 1 | 1 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 1 | 1 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5R_141_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5R_141_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5R_141_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5R_141_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5R_141_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5R_141_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 120 | 115 | 125 | 100 | 110 |
| Vsf | 140 | 135 | 135 | 140 | 135 |
| VoffsetOp | 90 | 70 | 65 | 85 | 65 |
| VIbias_PH | 100 | 105 | 100 | 105 | 105 |
Noise MAP
![[IMAGE] of](P_1x5R_141_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5R_141_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
