P_1x5R_118_A

Parts committed by Merkel Petra on date 11/15/2006

PartID
BBMBBM_118-1x5
VHDI1x5R_221

ROCROC waferLabel
ROC0W21_XA4KFIT55A
ROC1W21_XA4KFIT54C
ROC2W21_XA4KFIT53D
ROC3W21_XA4KFIT04C
ROC4W21_XA4KFIT53C

Inspected by Lockwood Gale on date 11/20/2006
LR_dev0.011
LL_dev0.070
FINAL COMMENT by Lockwood GaleNo assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/20/2006 by Lockwood Gale

P_1x5R_118_Aon 11/20/2006 1:38 PM

PLAQUETTE TESTED on 2006-11-20 by Isaac Childres

[IMAGE] of
IV_XML-File
Maximum Voltage 600 V
[IMAGE] of
LASER_XML-File
Depletion Voltage 48 V
Operational Voltage 88 V

ROCROC0ROC1ROC2ROC3ROC4
Ibias_DAC144123130136141
Vana134127137122135
Cal_Del7979778373
Vthrs_Comp7272777385
Unbumped00000
Dead00000
Noisy00000
Undecoded00000
Total BAD00000

ASSEMBLY_XML-File SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
[IMAGE] of I_BIAS_DAC_XML-File
[IMAGE] of VANA_XML-File
[IMAGE] of DEAD_XML-File
[IMAGE] of NOISY_XML-File
[IMAGE] of UNDECODED_XML-File
[IMAGE] of LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-27

Plaquette assigned to panel P4L_017
